7-10
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D601 8-719-054-32 DIODE ERA15-06TP3
D602 8-719-058-91 DIODE AG01A-V0
D603 8-719-200-82 DIODE 11ES2
D604 8-719-109-62 DIODE RD3.0ES-B1
D605 8-719-911-19 DIODE 1SS119
D606 8-719-313-17 DIODE AU02A-V0
D607 8-719-022-97 DIODE D2S4MF
D608 8-719-510-73 DIODE S3L20UF4
D609 8-719-313-17 DIODE AU02A-V0
D610 8-719-160-64 DIODE RD16F-B1
D611 8-719-911-19 DIODE 1SS119
D612 8-719-109-85 DIODE RD5.1ES-B2
D616 8-719-109-85 DIODE RD5.1ES-B2
D702 8-719-150-92 DIODE RD33ES-T1B
D980 8-719-110-08 DIODE RD8.2ES-B2 (688HF)
D981 8-719-110-08 DIODE RD8.2ES-B2 (688HF)
D982 8-719-911-19 DIODE 1SS119 (688HF)
< TERMINAL BOARD >
ET600 1-537-770-21 TERMINAL BOARD, GROUND
ET601 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE >
! F600 1-532-743-11 FUSE, GLASS CYLINDRICAL(DIA.5)
< FERRITE BEAD >
FB601 1-410-858-21 INDUCTOR 0UH
< FUSE HOLDER >
FH600 1-533-223-11 HOLDER, FUSE
FH601 1-533-223-11 HOLDER, FUSE
< IC >
IC101 8-759-481-46 IC LB1943
IC160 8-759-491-00 IC M37777M7A229GP-B (478,677HF,678HF)
IC160 8-759-525-07 IC M37777M7A235GP-C (688HF)
IC160 8-759-525-08 IC M37777M7A237GP-B
(EXCEPT 478,677HF,678HF,688HF)
IC161 8-759-432-32 IC ST24W02FM6TR
IC162 8-759-248-87 IC MM1256XF-BE
IC201 8-759-488-74 IC LA71534M-MPB
IC202 8-759-439-51 IC LC89978M-TE-L
IC260 8-759-352-17 IC HA118195NT
IC301 8-759-499-30 IC BA7755AF-E2
IC340 8-759-486-92 IC LA7256 (HiFi)
IC360 8-759-486-63 IC TDA9615H/N1,518
(L67HF,L68HF,L77HF,L78HF,X60HF)
IC360 8-759-486-64 IC TDA9615H/N1,557 (677HF,678HF,688HF)
IC403 8-742-042-00 HY B IC SBX1986-51
IC420 8-759-366-44 IC uPD16312GB-3B4
IC501 8-759-467-71 IC BU6188AFS-E2
IC601 8-759-438-18 IC PQ12RD08
! IC602 8-759-321-95 IC HA17431PA-TZ
IC733 8-598-438-00 IC SOUND MULTIPLEX MODULE MPA-450
(L67HF,L68HF,L77HF,L78HF,X60HF)
IC733 8-742-037-00 HY B IC SBX1837-51 (677HF,678HF,688HF)
IC980 8-759-356-27 IC NJM2129M-TE2 (688HF)
< IF BLOCK >
IF702 1-475-548-11 IF UNIT (IFZ-450ST) (US,Canadian)
IF702 1-475-548-21 IF UNIT (IFZ-450ST) (EXCEPT US,Canadian)
< JUMPER RESISTOR >
JR001 1-216-295-00 METAL CHIP 0 5% 1/10W
JR002 1-216-296-00 METAL CHIP 0 5% 1/8W
JR003 1-216-295-00 METAL CHIP 0 5% 1/10W
JR004 1-216-295-00 METAL CHIP 0 5% 1/10W
JR005 1-216-296-00 METAL CHIP 0 5% 1/8W
JR006 1-216-296-00 METAL CHIP 0 5% 1/8W
JR007 1-216-295-00 METAL CHIP 0 5% 1/10W
JR008 1-216-296-00 METAL CHIP 0 5% 1/8W
JR009 1-216-296-00 METAL CHIP 0 5% 1/8W
JR010 1-216-295-00 METAL CHIP 0 5% 1/10W
JR011 1-216-295-00 METAL CHIP 0 5% 1/10W
JR012 1-216-296-00 METAL CHIP 0 5% 1/8W
JR013 1-216-296-00 METAL CHIP 0 5% 1/8W
JR014 1-216-296-00 METAL CHIP 0 5% 1/8W
JR015 1-216-295-00 METAL CHIP 0 5% 1/10W
JR016 1-216-296-00 METAL CHIP 0 5% 1/8W
JR017 1-216-296-00 METAL CHIP 0 5% 1/8W
JR018 1-216-296-00 METAL CHIP 0 5% 1/8W
JR019 1-216-296-00 METAL CHIP 0 5% 1/8W
JR020 1-216-296-00 METAL CHIP 0 5% 1/8W
JR021 1-216-295-00 METAL CHIP 0 5% 1/10W
JR022 1-216-296-00 METAL CHIP 0 5% 1/8W
JR023 1-216-296-00 METAL CHIP 0 5% 1/8W
JR024 1-216-296-00 METAL CHIP 0 5% 1/8W
JR025 1-216-296-00 METAL CHIP 0 5% 1/8W
JR026 1-216-296-00 METAL CHIP 0 5% 1/8W
JR027 1-216-295-00 METAL CHIP 0 5% 1/10W
JR028 1-216-296-00 METAL CHIP 0 5% 1/8W
JR029 1-216-296-00 METAL CHIP 0 5% 1/8W
JR030 1-216-296-00 METAL CHIP 0 5% 1/8W
JR031 1-216-296-00 METAL CHIP 0 5% 1/8W
JR032 1-216-296-00 METAL CHIP 0 5% 1/8W
JR033 1-216-295-00 METAL CHIP 0 5% 1/10W
JR034 1-216-296-00 METAL CHIP 0 5% 1/8W
JR035 1-216-296-00 METAL CHIP 0 5% 1/8W
JR036 1-216-296-00 METAL CHIP 0 5% 1/8W
JR037 1-216-296-00 METAL CHIP 0 5% 1/8W
JR038 1-216-296-00 METAL CHIP 0 5% 1/8W
JR039 1-216-296-00 METAL CHIP 0 5% 1/8W
JR040 1-216-296-00 METAL CHIP 0 5% 1/8W
JR041 1-216-295-00 METAL CHIP 0 5% 1/10W
JR042 1-216-296-00 METAL CHIP 0 5% 1/8W
JR043 1-216-296-00 METAL CHIP 0 5% 1/8W
JR044 1-216-296-00 METAL CHIP 0 5% 1/8W
JR045 1-216-295-00 METAL CHIP 0 5% 1/10W
JR046 1-216-295-00 METAL CHIP 0 5% 1/10W
JR047 1-216-295-00 METAL CHIP 0 5% 1/10W
JR048 1-216-296-00 METAL CHIP 0 5% 1/8W
JR049 1-216-295-00 METAL CHIP 0 5% 1/10W
JR050 1-216-295-00 METAL CHIP 0 5% 1/10W
JR051 1-216-296-00 METAL CHIP 0 5% 1/8W
JR052 1-216-295-00 METAL CHIP 0 5% 1/10W
JR053 1-216-296-00 METAL CHIP 0 5% 1/8W
JR054 1-216-296-00 METAL CHIP 0 5% 1/8W
JR055 1-216-296-00 METAL CHIP 0 5% 1/8W
MA-317
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
