7-11
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
JR056 1-216-295-00 METAL CHIP 0 5% 1/10W
JR057 1-216-296-00 METAL CHIP 0 5% 1/8W
JR058 1-216-295-00 METAL CHIP 0 5% 1/10W
JR059 1-216-296-00 METAL CHIP 0 5% 1/8W
JR060 1-216-296-00 METAL CHIP 0 5% 1/8W
JR061 1-216-296-00 METAL CHIP 0 5% 1/8W
JR062 1-216-295-00 METAL CHIP 0 5% 1/10W
JR063 1-216-296-00 METAL CHIP 0 5% 1/8W
JR064 1-216-296-00 METAL CHIP 0 5% 1/8W
JR065 1-216-296-00 METAL CHIP 0 5% 1/8W
JR066 1-216-296-00 METAL CHIP 0 5% 1/8W
JR067 1-216-296-00 METAL CHIP 0 5% 1/8W
JR068 1-216-296-00 METAL CHIP 0 5% 1/8W
JR069 1-216-295-00 METAL CHIP 0 5% 1/10W
JR070 1-216-296-00 METAL CHIP 0 5% 1/8W
JR071 1-216-296-00 METAL CHIP 0 5% 1/8W
JR072 1-216-296-00 METAL CHIP 0 5% 1/8W
JR073 1-216-296-00 METAL CHIP 0 5% 1/8W
JR074 1-216-295-00 METAL CHIP 0 5% 1/10W
JR075 1-216-295-00 METAL CHIP 0 5% 1/10W
JR076 1-216-295-00 METAL CHIP 0 5% 1/10W
JR351 1-216-295-00 METAL CHIP 0 5% 1/10W
(HiFi)
JR352 1-216-296-00 METAL CHIP 0 5% 1/8W
(HiFi)
JR353 1-216-295-00 METAL CHIP 0 5% 1/10W
(HiFi)
JR354 1-216-296-00 METAL CHIP 0 5% 1/8W
(HiFi)
JR355 1-216-295-00 METAL CHIP 0 5% 1/10W
(HiFi)
< JUMPER RESISTOR >
JS324 1-216-295-00 METAL CHIP 0 5% 1/10W
(MONO)
< COIL >
L161 1-414-936-21 INDUCTOR 22uH
L163 1-414-936-21 INDUCTOR 22uH
L201 1-414-946-21 INDUCTOR 39uH
L202 1-414-940-21 INDUCTOR 100uH
L204 1-414-940-21 INDUCTOR 100uH
L261 1-414-939-21 INDUCTOR 68uH
L262 1-414-940-21 INDUCTOR 100uH
L263 1-414-940-21 INDUCTOR 100uH
L331 1-414-940-21 INDUCTOR 100uH
L341 1-414-940-21 INDUCTOR 100uH (HiFi)
L502 1-414-936-21 INDUCTOR 22uH
L560 1-414-940-21 INDUCTOR 100uH
L601 1-403-588-11 INDUCTOR 0uH
L602 1-403-588-11 INDUCTOR 0uH
L603 1-410-526-11 INDUCTOR 10uH
L604 1-410-519-11 INDUCTOR 68uH
L702 1-414-938-21 INDUCTOR 47uH
L703 1-414-930-21 INDUCTOR 2.2uH
L704 1-414-938-21 INDUCTOR 47uH
L731 1-414-934-21 INDUCTOR 10uH (HiFi)
< LINE FILTER >
LF600 1-424-117-11 FILTER, LINE
< FLUORESCENT INDICATOR >
ND420 1-517-732-11 TUBE, FLUORESCENT INDICATOR
< PHOTO INTERRUPTER >
PH101 8-749-013-23 PHOTO INTERRUPTER GP3S120
PH102 8-749-013-23 PHOTO INTERRUPTER GP3S120
! PH600 8-749-014-24 COUPLER, PHOTO ON3131-S (LF)
< IC LINK >
! PS101 1-533-586-11 LINK, IC 315mA
! PS600 1-533-592-11 LINK, IC 1.6A
< TRANSISTOR >
Q101 8-729-042-88 TRANSISTOR RPT-37PBT32
Q102 8-729-042-88 TRANSISTOR RPT-37PBT32
Q103 8-729-281-53 TRANSISTOR 2SC1815-GR
Q201 8-729-230-49 TRANSISTOR 2SC2712-G
Q202 8-729-230-49 TRANSISTOR 2SC2712-G
Q208 8-729-230-49 TRANSISTOR 2SC2712-G
Q209 8-729-216-21 TRANSISTOR 2SA1162Y-TE85L
Q210 8-729-230-49 TRANSISTOR 2SC2712-G
Q211 8-729-230-49 TRANSISTOR 2SC2712-G
Q260 8-729-230-49 TRANSISTOR 2SC2712-G
Q301 8-729-281-53 TRANSISTOR 2SC1815-GR
Q331 8-729-802-91 TRANSISTOR 2SD879
Q387 8-729-230-49 TRANSISTOR 2SC2712-G (MONO)
Q401 8-729-421-22 TRANSISTOR UN2211
Q501 8-729-216-21 TRANSISTOR 2SA1162Y-TE85L
Q502 8-729-010-05 TRANSISTOR MSB709-RT1
Q560 8-729-010-05 TRANSISTOR MSB709-RT1
Q601 8-729-904-98 TRANSISTOR 2SC4054P
Q602 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q603 8-729-140-98 TRANSISTOR 2SD773
Q604 8-729-010-25 TRANSISTOR MSD601-RT1
Q605 8-729-140-93 TRANSISTOR 2SB733-34
< RESISTOR >
R101 1-249-413-11 CARBON 470 5% 1/4W F
R102 1-216-089-00 METAL CHIP 47K 5% 1/10W
R103 1-216-089-00 METAL CHIP 47K 5% 1/10W
R104 1-216-081-00 METAL CHIP 22K 5% 1/10W
R105 1-216-081-00 METAL CHIP 22K 5% 1/10W
R106 1-249-400-11 CARBON 39 5% 1/4W F
R107 1-249-400-11 CARBON 39 5% 1/4W F
R109 1-216-089-00 METAL CHIP 47K 5% 1/10W
R110 1-216-089-00 METAL CHIP 47K 5% 1/10W
R111 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R112 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R115 1-216-089-00 METAL CHIP 47K 5% 1/10W
R116 1-216-089-00 METAL CHIP 47K 5% 1/10W
R117 1-216-041-00 METAL CHIP 470 5% 1/10W
R118 1-216-089-00 METAL CHIP 47K 5% 1/10W
R119 1-216-077-00 METAL CHIP 15K 5% 1/10W
R120 1-249-417-11 CARBON 1K 5% 1/4W F
R121 1-216-077-00 METAL CHIP 15K 5% 1/10W
R122 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
MA-317
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
