5-16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R734 1-216-049-91 METAL GLAZE 1K 5% 1/10W
(715B,720B,720BZ,720EE,720EG)
R850 1-216-025-91 METAL GLAZE 100 5% 1/10W
(EXCEPT 570EE,720EE)
R851 1-216-079-00 METAL CHIP 18K 5% 1/10W
(EXCEPT 570EE,720EE)
R852 1-216-083-00 METAL CHIP 27K 5% 1/10W
(EXCEPT 570EE,720EE)
R853 1-216-049-91 METAL GLAZE 1K 5% 1/10W
(EXCEPT 570EE,720EE)
R856 1-216-097-91 METAL GLAZE 100K 5% 1/10W
(EXCEPT 570EE,720EE)
R857 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(EXCEPT 570EE,720EE)
R858 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(EXCEPT 570EE,720EE)
R859 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
(EXCEPT 570EE,720EE)
R860 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
(EXCEPT 570EE,720EE)
R861 1-216-117-00 METAL CHIP 680K 5% 1/10W
(EXCEPT 570EE,720EE)
R862 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(EXCEPT 570EE,720EE)
R930 1-216-073-00 METAL CHIP 10K 5% 1/10W
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
R931 1-216-097-91 METAL GLAZE 100K 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R932 1-216-097-91 METAL GLAZE 100K 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R933 1-216-073-00 METAL CHIP 10K 5% 1/10W
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
R934 1-216-073-00 METAL CHIP 10K 5% 1/10W
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
R936 1-216-025-91 METAL GLAZE 100 5% 1/10W
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
R938 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R939 1-216-022-00 METAL CHIP 75 5% 1/10W
(EXCEPT 325,475,570EE,720EE,720EG)
R940 1-216-049-91 METAL GLAZE 1K 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R941 1-216-022-00 METAL CHIP 75 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R943 1-216-085-00 METAL CHIP 33K 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R944 1-216-089-91 METAL GLAZE 47K 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R945 1-216-041-00 METAL CHIP 470 5% 1/10W
(EXCEPT 325,475,570EE,720EE,720EG)
R946 1-216-041-00 METAL CHIP 470 5% 1/10W
(EXCEPT 325,475,570EE,720EE,720EG)
R947 1-216-041-00 METAL CHIP 470 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R948 1-216-041-00 METAL CHIP 470 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R949 1-216-073-00 METAL CHIP 10K 5% 1/10W
(715B,717VC,720B,720BZ,720NP,720VC)
R950 1-216-073-00 METAL CHIP 10K 5% 1/10W
(570EG,715B,717VC,720B,720BZ,720NP,720VC)
R951 1-216-295-91 CONDUCTOR, CHIP(2012)
(EXCEPT 325,475,570EE,720EE,720EG)
< MODULATOR >
RFU700 1-475-058-11 MODULATOR, RF(RFU-2110)
(715B,720B,720BZ)
RFU700 1-475-059-11 MODULATOR, RF(RFU-2101)
(717VC,720EG,720EX,720NC,720NP,720UX,720VC,720VP,725NC)
< SWITCH >
S100 1-570-953-11 SWITCH, PUSH (1 KEY)
(CASSETTE IN/REC PROOF)
S160 1-571-588-11 SWITCH, SLIDE(NTSC PB)
S700 1-571-588-11 SWITCH, SLIDE(RF MODULATOR ON/OFF)
< TUNER >
TU701 1-693-359-11 TUNER, MODULATOR IF (570EE,720EE)
TU701 1-693-360-11 TUNER, MODULATOR IF (325,475,570EG)
TU703 1-693-361-11 TUNER, IF(BTF-3WC425)(720EG)
TU703 1-693-362-11 TUNER, IF(BTF-3WC443)(720BZ)
TU703 1-693-364-11 TUNER, IF(BTF-3WC444)(715B,720B)
TU703 1-693-365-11 TUNER, IF(BTF-3WC433)(720EX)
TU703 1-693-366-11 TUNER, IF(BTF-3WU602)(720UX)
TU703 1-693-367-11 TUNER, IF(BTF-3WC412)(720NC,720NP,725NC)
TU703 1-693-368-11 TUNER, IF(BTF-3WC402)(717VC,720VC,720VP)
< VIBRATOR >
X160 1-760-494-11 VIBRATOR, CRYSTAL 16MHz
X201 1-579-608-11 VIBRATOR, CRYSTAL 4.43MHz
X500 1-577-289-11 VIBRATOR, CRYSTAL 17.734475MHz
* A-6791-186-A PS-385 BOARD, COMPLETE
**********************
(Ref.No.: 5,000 Series)
3-970-608-21 SUMITITE (B3), +BV
< CAPACITOR >
! C600 1-117-617-11 FILM 0.22uF 20% 275V
! C601 1-117-616-11 FILM 0.1uF 20% 275V
! C602 1-113-915-11 CERAMIC 0.001uF 20% 250V
! C603 1-113-915-11 CERAMIC 0.001uF 20% 250V
! C604 1-113-915-11 CERAMIC 0.001uF 20% 250V
! C605 1-113-915-11 CERAMIC 0.001uF 20% 250V
! C606 1-113-915-11 CERAMIC 0.001uF 20% 250V
C607 1-117-615-11 ELECT 68uF 20% 400V
C608 1-126-963-11 ELECT 4.7uF 20% 50V
C609 1-130-491-00 MYLAR 0.047uF 5% 50V
C612 1-130-491-00 MYLAR 0.047uF 5% 50V
C613 1-115-741-11 ELECT 0.0022F 20% 10V
C615 1-111-042-11 ELECT 0.0012F 20% 16V
C616 1-136-165-00 MYLAR 0.1uF 10% 50V
C617 1-126-935-11 ELECT 470uF 20% 16V
C618 1-126-926-11 ELECT 1000uF 20% 10V
C619 1-126-934-11 ELECT 220uF 20% 16V
C621 1-126-967-11 ELECT 47uF 20% 16V
C624 1-126-934-11 ELECT 220uF 20% 16V
C625 1-128-551-11 ELECT 22uF 20% 25V
MA-286 PS-385
Note : The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
