5-17
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C626 1-126-933-11 ELECT 100uF 20% 16V
C627 1-126-967-11 ELECT 47uF 20% 50V
C628 1-128-551-11 ELECT 22uF 20% 25V
C629 1-126-924-11 ELECT 330uF 20% 10V
C630 1-126-924-11 ELECT 330uF 20% 10V
C633 1-111-084-11 ELECT 220uF 20% 35V
C634 1-126-949-11 ELECT 220uF 20% 35V
C636 1-126-968-11 ELECT 100uF 20% 50V
C637 1-162-134-11 CERAMIC 470PF 10% 2KV
< CONNECTOR >
CN600 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN601 1-569-341-11 CONNECTOR, BOARD TO BOARD 19P
< DIODE >
D600 8-719-051-93 DIODE DF06M-6031
D602 8-719-975-89 DIODE ERA15-02TP3
D603 8-719-981-97 DIODE MTZJ-3.0A
D604 8-719-991-33 DIODE 1SS133T-77
D605 8-719-043-76 DIODE AK04V0
D606 1-809-649-11 DIODE RK44LF-L1
D607 8-719-313-17 DIODE AU02A-V0
D608 8-719-510-73 DIODE S3L20UF4
D609 8-719-313-17 DIODE AU02A-V0
D610 8-719-059-64 DIODE RD16F-T8B2
D612 8-719-911-19 DIODE 1SS119
D613 8-719-109-85 DIODE RD5.1ES-B2
D614 8-719-911-19 DIODE 1SS119
< TERMINAL BOARD >
ET600 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE >
! F600 1-533-827-11 FUSE (HOLDER TO) T2A 250V
< IC >
IC601 8-759-438-18 IC PQ12RD08
IC602 8-759-035-35 IC TL431CLPRA
< JUMPER RESISTOR >
JS612 1-216-295-91 CONDUCTOR, CHIP (2012)
< COIL >
L600 1-403-588-11 CIL, CHOKE 22uH
L601 1-403-588-11 CIL, CHOKE 22uH
L602 1-408-397-00 INDUCTOR 1uH
L603 1-408-397-00 INDUCTOR 1uH
L604 1-414-792-11 INDUCTOR 0uH
< LINE FILTER >
LF600 1-424-485-11 FILTER, LINE
LF601 1-409-977-11 FILTER, LINE
LF602 1-409-977-11 FILTER, LINE
< PHOTOCOUPLER >
! PH600 8-749-013-04 PHOTOCOUPLER MOC8104TV
< IC LINK >
! PS600 1-532-841-21 LINK, IC 1.6A
! PS601 1-532-841-21 LINK, IC 1.6A
! PS602 1-533-593-11 LINK, IC 2A
! PS603 1-532-841-21 LINK, IC 1.6A
< TRANSISTOR >
Q600 8-729-024-00 TRANSISTOR 2SC3377-T93Q
Q601 8-729-032-85 TRANSISTOR 2SC4231LM
Q602 8-729-140-93 TRANSISTOR 2SB733-34
Q603 8-729-421-22 TRANSISTOR UN2211
Q604 8-729-018-99 TRANSISTOR 2SD2394-F
Q605 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q607 8-729-140-96 TRANSISTOR KSC1008
Q608 8-729-901-06 TRANSISTOR DTA144EK
Q610 8-729-140-96 TRANSISTOR KSC1008
Q611 8-729-901-06 TRANSISTOR DTA144EK
Q612 8-729-421-19 TRANSISTOR UN2213
Q613 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q614 8-729-119-77 TRANSISTOR 2SA1175-FEK
< RESISTOR >
! R600 1-214-947-00 METAL 2.7M 1% 1/2W
R601 1-247-887-00 CARBON 220K 5% 1/4W
R602 1-247-887-00 CARBON 220K 5% 1/4W
R603 1-249-429-11 CARBON 10K 5% 1/4W
R604 1-215-885-00 METAL OXIDE 68 5% 2W F
R606 1-215-416-00 METAL 620 1% 1/6W
R607 1-247-807-31 CARBON 100 5% 1/4W
R608 1-249-404-00 CARBON 82 5% 1/4W F
R609 1-215-428-00 METAL 2K 1% 1/6W
R610 1-249-406-11 CARBON 120 5% 1/4W F
R611 1-215-425-00 METAL 1.5K 1% 1/6W
R612 1-249-421-11 CARBON 2.2K 5% 1/4W F
R613 1-249-421-11 CARBON 2.2K 5% 1/4W F
R614 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R615 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R616 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R617 1-249-417-11 CARBON 1K 5% 1/4W F
R618 1-247-815-91 CARBON 220 5% 1/4W
R620 1-249-417-11 CARBON 1K 5% 1/4W F
R621 1-216-363-00 METAL OXIDE 0.33 5% 2W F
R622 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R623 1-216-073-00 METAL CHIP 10K 5% 1/10W
R624 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R625 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R626 1-247-815-91 CARBON 220 5% 1/4W
R627 1-249-421-11 CARBON 2.2K 5% 1/4W F
< TRANSFORMER >
T600 1-431-167-11 TRANSFORMER, RCC CONVERTER
PS-385
Note : The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
To Next Page
