5-19
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< IC >
IC140 8-759-438-83 IC BA6305F
IC141 8-759-510-73 IC BA10393F-E2
IC260 8-759-352-17 IC HA118195NT (EXCEPT 325)
IC260 8-759-357-84 IC HA118295NT (325)
IC301 8-759-089-84 IC BA7755AF-T1
IC340 8-759-055-49 IC AN3327K (715B,717VC,720,725)
< JUMPER RESISTOR >
JR501 1-216-296-91 CONDUCTOR, CHIP(3216)
JR502 1-216-295-91 CONDUCTOR, CHIP(2012)
< JUMPER RESISTOR >
JS331 1-216-295-91 CONDUCTOR, CHIP(2012)
(325,475,715B,717VC,720,725)
< COIL >
L140 1-408-982-11 INDUCTOR 100uH
L262 1-408-970-21 INDUCTOR 10uH
L263 1-408-982-11 INDUCTOR 100uH
L321 1-408-982-11 INDUCTOR 100uH
L331 1-410-687-11 INDUCTOR 1.2mH (570)
L341 1-408-982-11 INDUCTOR 100uH
(715B,717VC,720,725)
< IC LINK >
! PS331 1-533-586-31 LINK, IC 0.315A (570)
< TRANSISTOR >
Q141 8-729-901-06 TRANSISTOR DTA144EK
Q260 8-729-230-49 TRANSISTOR 2SC2712-YG
Q321 8-729-802-91 TRANSISTOR 2SD879
Q331 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q (570)
Q332 8-729-900-51 TRANSISTOR DTA114TK (570)
< RESISTOR >
R140 1-216-117-00 METAL CHIP 680K 5% 1/10W
R141 1-216-037-00 METAL CHIP 330 5% 1/10W
R142 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R143 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R144 1-216-043-91 METAL GLAZE 560 5% 1/10W
R145 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R147 1-208-830-11 METAL GLAZE 100K 0.50% 1/10W
R148 1-208-830-11 METAL GLAZE 100K 0.50% 1/10W
R149 1-208-830-11 METAL GLAZE 100K 0.50% 1/10W
R150 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R151 1-208-830-11 METAL GLAZE 100K 0.50% 1/10W
R152 1-216-111-91 METAL GLAZE 390K 5% 1/10W
R153 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R155 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R157 1-216-081-00 METAL CHIP 22K 5% 1/10W
R260 1-216-041-00 METAL CHIP 470 5% 1/10W
(EXCEPT 325)
R260 1-216-045-00 METAL CHIP 680 5% 1/10W
(325)
R261 1-216-041-00 METAL CHIP 470 5% 1/10W
(EXCEPT 325)
R262 1-216-295-91 CONDUCTOR, CHIP(2012)
R263 1-216-295-91 CONDUCTOR, CHIP(2012)
R264 1-216-295-91 CONDUCTOR, CHIP(2012)
R265 1-216-295-91 CONDUCTOR, CHIP(2012) (EXCEPT 325)
R266 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(325)
R266 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
(EXCEPT 325)
R267 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
(EXCEPT 325)
R267 1-216-073-00 METAL CHIP 10K 5% 1/10W
(325)
R268 1-216-081-00 METAL CHIP 22K 5% 1/10W
R269 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
(EXCEPT 325)
R269 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
(325)
R270 1-216-081-00 METAL CHIP 22K 5% 1/10W
R271 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R272 1-216-081-00 METAL CHIP 22K 5% 1/10W
R273 1-216-081-00 METAL CHIP 22K 5% 1/10W
R274 1-216-075-00 METAL CHIP 12K 5% 1/10W
R275 1-216-075-00 METAL CHIP 12K 5% 1/10W
R276 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R278 1-216-025-91 METAL GLAZE 100 5% 1/10W
(325)
R317 1-216-079-00 METAL CHIP 18K 5% 1/10W
R321 1-249-401-11 CARBON 47 5% 1/4W F
R322 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
(EXCEPT 325,570)
R322 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
(325)
R322 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
(570)
R323 1-217-671-11 METAL CHIP 1 5% 1/10W
R324 1-249-408-11 CARBON 180 5% 1/4W F
R331 1-216-295-91 CONDUCTOR, CHIP(2012) (570)
R332 1-216-083-00 METAL CHIP 27K 5% 1/10W
(570)
R333 1-249-394-11 CARBON 12 5% 1/4W F
(570)
R335 1-126-735-11 ELECT 10MF 20% 100V
(570)
R341 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
(715B,717VC,720,725)
R342 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(715B,717VC,720,725)
R343 1-216-073-00 METAL CHIP 10K 5% 1/10W
(715B,717VC,720,725)
R344 1-216-079-00 METAL CHIP 18K 5% 1/10W
(715B,717VC,720,725)
R345 1-216-097-91 METAL GLAZE 100K 5% 1/10W
(715B,717VC,720,725)
R346 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(715B,717VC,720,725)
R347 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(715B,717VC,720,725)
R348 1-216-097-91 METAL GLAZE 100K 5% 1/10W
(715B,717VC,720,725)
R350 1-216-033-00 METAL CHIP 220 5% 1/10W
(715B,717VC,720,725)
R351 1-216-035-00 METAL CHIP 270 5% 1/10W
(715B,717VC,720,725)
R356 1-216-035-00 METAL CHIP 270 5% 1/10W
(715B,717VC,720,725)
RP-217
Note : The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
