Ref. No. Part No. Description Remarks
5-20E
Ref. No. Part No. Description Remarks
< TRANSFORMER >
T321 1-431-097-11 TRANSFORMER, BIAS OSCILLATION
(EXCEPT 570)
T321 1-431-100-11 TRANSFORMER, BIAS OSCILLATION (570)
T331 1-423-415-11 TRANSFORMER, BIAS OSCILLATION (570)
MISCELLANEOUS
*************
11 1-762-844-21 SWITCH, ROTARY (570)
! 15 1-782-012-11 CORD, POWER
17 1-777-960-11 CABLE, FLAT (FFM-13) 29P
158 1-500-144-11 HEAD, FE
164 A-6736-105-A ACE BLOCK ASSY
165 1-506-485-11 PIN, CONNECTOR 6P
203 1-759-183-11 DRUM ASSY, DZH-78A-R(M901) (325)
203 1-759-371-11 DRUM ASSY, DZH-65A-R(M901) (475,570)
203 1-759-373-11 DRUM ASSY, DZH-86A-R(M901)
(715B,717VC,720,725)
260 1-762-076-11 SWITCH, ROTARY
M902 1-698-409-14 MOTOR, DC(CAPSTAN)
M903 X-3943-883-1 MOTOR ASSY, CAM
ACCESSORIES & PACKING MATERIALS
*******************************
1-696-593-11 CORD, CONNECTION (PAL)(FOR RF)1.5m
1-770-019-11 ADAPTOR, CONVERSION PLUG 3P
(720EX,720UX)
1-770-321-11 ADAPTOR, CONVERSION 6P (720EE)
1-770-321-21 ADAPTOR, CONVERSION 4P (570EE)
3-858-881-11 MANUAL, INSTRUCTION (ENGLISH)
(720EX,720UX)
3-858-881-21 MANUAL, INSTRUCTION (FRENCH)
(720NC,720VP,725NC)
3-858-881-31 MANUAL, INSTRUCTION (GERMAN)
(717VC,720NC,720VC,720VP,725NC)
3-858-881-41 MANUAL, INSTRUCTION (FRENCH)
(720B,720BZ)
3-858-881-51 MANUAL, INSTRUCTION (DUTCH)
(720NC,720VP,725NC)
3-858-881-61 MANUAL, INSTRUCTION (ITALIAN)(720VP)
3-858-881-71 MANUAL, INSTRUCTION (SPANISH)(720NP)
3-858-881-81 MANUAL, INSTRUCTION (PORTUGUESE)
(720NP)
3-858-882-11 MANUAL, INSTRUCTION (SWEDISH)
(720NC,725NC)
3-858-882-21 MANUAL, INSTRUCTION (FINISH)
(720NC,725NC)
3-858-882-31 MANUAL, INSTRUCTION (DANISH)
(720NC,725NC)
3-858-883-11 MANUAL, INSTRUCTION (ENGLISH)(720EG)
3-858-883-21 MANUAL, INSTRUCTION (CZECH)(720EG)
3-858-883-31 MANUAL, INSTRUCTION (POLISH)(720EG)
3-858-883-41 MANUAL, INSTRUCTION (HUNGARIAN)(720EG)
3-858-883-51 MANUAL, INSTRUCTION (ENGLISH)(720EE)
3-858-883-61 MANUAL, INSTRUCTION (RUSSIAN)(720EE)
3-858-884-11 MANUAL, INSTRUCTION (ENGLISH)(570EG)
3-858-884-21 MANUAL, INSTRUCTION (CZECH)(570EG)
3-858-884-31 MANUAL, INSTRUCTION (POLISH)(570EG)
3-858-884-41 MANUAL, INSTRUCTION (HUNGARIAN)(570EG)
3-858-884-51 MANUAL, INSTRUCTION (ENGLISH)(570EE)
3-858-884-61 MANUAL, INSTRUCTION (RUSSIAN)(570EE)
3-858-885-11 MANUAL, INSTRUCTION (CZECH)(475)
3-858-885-21 MANUAL, INSTRUCTION (ENGLISH)(325)
3-858-885-31 MANUAL, INSTRUCTION (CZECH)(325)
3-858-885-41 MANUAL, INSTRUCTION (POLISH)(325)
3-858-885-51 MANUAL, INSTRUCTION (HUNGARIAN)(325)
3-859-420-21 MANUAL, INSTRUCTION (FRENCH)(715B)
* 3-972-892-01 INDIVIDUAL CARTON
(720NC,720NP,720VC,720VP)
* 3-972-892-11 INDIVIDUAL CARTON(720B,720BZ)
* 3-972-892-21 INDIVIDUAL CARTON(720EX,720UX)
* 3-972-892-31 INDIVIDUAL CARTON(717VC)
* 3-972-892-41 INDIVIDUAL CARTON(725NC)
* 3-972-892-51 INDIVIDUAL CARTON(715B)
* 3-972-893-01 CUSHION
* 3-974-278-01 INDIVIDUAL CARTON(720EG)
* 3-974-278-11 INDIVIDUAL CARTON(720EE)
* 3-974-278-21 INDIVIDUAL CARTON(570EG)
* 3-974-278-31 INDIVIDUAL CARTON(570EE)
* 3-974-278-41 INDIVIDUAL CARTON(475)
* 3-974-278-51 INDIVIDUAL CARTON(325)
* 3-974-583-01 SPACER
**************
HARDWARE LIST
**************
#1 7-682-547-04 SCREW +P 3X6
#2 7-685-646-79 SCREW (3X8)
#5 7-624-190-61 STOP RING 2.4,TYPE-CS
#6 7-628-254-10 SCREW +PS 2.6X6
#7 7-624-106-04 STOP RING 3.0,TYPE-E
#8 7-682-645-01 SCREW +PS 3X4
RP-217
Note : The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
