SLV-LX80S
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-9
MA-402
GK-12
<RESISTOR>
R533 1-216-021-00 RES-CHIP 68 5% 1/10W
(ED515/ED616/ED818/
ED915/ED919/EZ715/EZ717)
R534 1-216-097-11 RES-CHIP 100K 5% 1/10W
(ED515/ED616/ED818/
ED915/ED919/EZ715/EZ717)
R535 1-216-097-11 RES-CHIP 100K 5% 1/10W
(ED515/ED616/ED818/
ED915/ED919/EZ715/EZ717)
<SWITCH>
S500 1-762-196-21 SWITCH, TACT
A-6713-872-A GK-12 BOARD COMPLETE
(EZ715AS/EZ717AS)
*********************
<CAPACITOR>
C003 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C006 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C007 1-164-699-11 CERAMIC CHIP 0.0033uF 5.00% 50V
C008 1-164-699-11 CERAMIC CHIP 0.0033uF 5.00% 50V
C009 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C010 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C011 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C012 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C013 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C014 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C015 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C016 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C017 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C018 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C022 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C023 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
< CONNECTOR >
* CN001 1-691-183-11 CONNECTOR (BOARD TO BOARD) 13P
< IC >
IC001 8-759-579-30 IC TDA9873H/V1, 518
< JUMPER RESISTOR >
JS002 1-216-295-00 METAL CHIP 0 5% 1/10W
JS003 1-216-295-00 METAL CHIP 0 5% 1/10W
< RESISTOR >
R001 1-216-295-00 METAL CHIP 0 5% 1/10W
R002 1-216-295-00 METAL CHIP 0 5% 1/10W
R004 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R005 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R006 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R007 1-216-045-00 METAL CHIP 680 5% 1/10W
R008 1-216-041-00 METAL CHIP 470 5% 1/10W
R009 1-216-041-00 METAL CHIP 470 5% 1/10W
R010 1-208-803-11 METAL CHIP 7.5K 0.5% 1/10W
R011 1-216-295-00 METAL CHIP 0 5% 1/10W
R012 1-216-298-00 METAL CHIP 2.2 5% 1/10W
< VARIABLE RESISTOR >
RV001 1-241-783-11 RES, ADJ, CARBON 2.2K
< VIBRATOR >
X001 1-781-353-11 VIBRATOR, CRYSTAL (4MHz)
************************************************************
A-6713-865-A MA-402 BOARD COMPLETE (ED818)
A-6713-866-A MA-402 BOARD COMPLETE (ED919)
A-6713-867-A MA-402 BOARD COMPLETE (EZ717NZ)
A-6713-868-A MA-402 BOARD COMPLETE (EZ715AS)
A-6713-869-A MA-402 BOARD COMPLETE (ED815)
A-6713-871-A MA-402 BOARD COMPLETE (EZ717AS)
A-6713-873-A MA-402 BOARD COMPLETE (ED817)
A-6713-874-A MA-402 BOARD COMPLETE (ED915)
A-6713-879-A MA-402 BOARD COMPLETE (EZ715NZ)
A-6713-885-A MA-402 BOARD COMPLETE (ED115/ED215)
A-6713-886-A MA-402 BOARD COMPLETE (ED313: ME, SG)
A-6713-888-A MA-402 BOARD COMPLETE (ED515)
A-6713-890-A MA-402 BOARD COMPLETE (ED616: ME, SG)
A-6713-891-A MA-402 BOARD COMPLETE (EZ111)
A-6713-892-A MA-402 BOARD COMPLETE (EZ414)
A-6713-893-A MA-402 BOARD COMPLETE (EZ212)
A-6794-816-A MA-402 BOARD COMPLETE (ED313)
A-6794-817-A MA-402 BOARD COMPLETE (ED616)
**********************
3-064-645-01 HOLDER, FL
3-065-718-01 SINK, HEAT
3-960-273-11 SPACER, TOP END
3-960-274-01 SPACER, LED
<CAPACITOR>
C001 1-163-009-11 CERAMIC CHIP 0.001uF 10.00% 50V
C002 1-163-009-11 CERAMIC CHIP 0.001uF 10.00% 50V
C003 1-163-009-11 CERAMIC CHIP 0.001uF 10.00% 50V
C004 1-163-009-11 CERAMIC CHIP 0.001uF 10.00% 50V
C005 1-128-057-11 ELECT 330uF 20.00% 6.3V
C006 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C007 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
(EZ111/EZ212/ED313)
C008 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C009 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C010 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C011 1-164-232-11 CERAMIC CHIP 0.01uF 10.00% 50V
C012 1-164-232-11 CERAMIC CHIP 0.01uF 10.00% 50V
C013 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C014 1-164-232-11 CERAMIC CHIP 0.01uF 10.00% 50V
C015 1-163-231-11 CERAMIC CHIP 15PF 5.00% 50V
