8-2. ELECTRICAL PARTS LIST
A-6713-877-A DI-081 BOARD COMPLETE
**********************
<CONNECTOR>
CN901 1-695-368-31 CONNECTOR, FFC/FPC 7P
CN901 1-784-449-11 CONNECTOR, FFC/FPC 7P
<DIODE>
D900 8-719-056-06 DIODE SLR-342DCT31
<RESISTOR>
R900 1-216-295-00 SHORT 0
R902 1-216-043-91 RES-CHIP 560 5% 1/10W
<SWITCH>
S900 1-762-196-21 SWITCH, TACT
S901 1-418-059-22 ENCODER, ROTARY
A-6713-876-A DM-098 BOARD COMPLETE
**********************
<CONNECTOR>
CN471 1-770-514-31 CONNECTOR, FFC/FPC 5P
CN471 1-784-447-11 CONNECTOR, FFC/FPC 5P
<CHIP CONDUCTOR>
JR461 1-216-295-00 SHORT 0
<RESISTOR>
R465 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R467 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R468 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R469 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R470 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R474 1-216-295-00 SHORT 0
R475 1-216-295-00 SHORT 0
<SWITCH>
S462 1-762-196-21 SWITCH, TACT (6 EJECT)
S463 1-762-196-21 SWITCH, TACT (r REC)
S466 1-762-196-21 SWITCH, TACT (0 REW)
S467 1-762-196-21 SWITCH, TACT (p STOP)
S468 1-762-196-21 SWITCH, TACT (( PLAY)
S469 1-762-196-21 SWITCH, TACT () FF)
S472 1-762-196-21 SWITCH, TACT (P PAUSE)
A-6713-870-A FJ-031 BOARD COMPLETE
(ED115/ED215/ED313/EZ111/EZ212/EZ414)
A-6713-878-A FJ-031 BOARD COMPLETE
(ED818/ED915/ED919/EZ715/EZ717)
A-6713-889-A FJ-031 BOARD COMPLETE
(ED515/ED616)
**********************
<CONNECTOR>
CN532 1-695-368-31 CONNECTOR, FFC/FPC 7P
CN532 1-784-449-11 CONNECTOR, FFC/FPC 7P
<JACK>
CNJ531 1-770-021-11 JACK, PIN 3P (ED515/ED616/ED818/
ED915/ED919/EZ715/EZ717)
<DIODE>
D531 8-719-071-15 DIODE HZM6.8ZWA1TL (ED515/ED616/ED818/
ED915/ED919/EZ715/EZ717)
D532 8-719-071-15 DIODE HZM6.8ZWA1TL (ED515/ED616/ED818/
ED915/ED919/EZ715/EZ717)
D533 8-719-071-15 DIODE HZM6.8ZWA1TL (ED515/ED616/ED818/
ED915/ED919/EZ715/EZ717)
D534 8-719-017-09 DIODE 02DZ6.2-TPH3 (ED515/ED616/ED818/
ED915/ED919/EZ715/EZ717)
<JUMPER SELECTOR>
JS531 1-216-296-00 SHORT 0 (ED515/ED616/
ED818/ED915/ED919/EZ715/EZ717)
JS532 1-216-296-00 SHORT 0 (ED515/ED616/
ED818/ED915/ED919/EZ715/EZ717)
JS534 1-216-295-00 SHORT 0
