SLV-LX80S
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-13
MA-402
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
D609 8-719-083-43 DIODE 31DQ06-FA7
D611 8-719-313-17 DIODE AU02A-V0
D612 8-719-313-17 DIODE AU02A-V0
D613 8-719-043-76 DIODE AK04V0
D614 8-719-160-64 DIODE RD16F-T8B1
D623 8-719-109-93 DIODE RD6.2ES-T1B2
D624 8-719-063-70 DIODE D1NL20U-TA2
D625 8-719-110-49 DIODE MTZJ-T-77-18B
D701 8-719-150-92 DIODE RD33ES-T1B3
D901 8-719-109-93 DIODE RD6.2ES-T1B2
D902 8-719-109-93 DIODE RD6.2ES-T1B2
<GROUND TERMINAL>
ET600 1-537-771-21 TERMINAL BOARD, GROUND
ET601 1-537-771-21 TERMINAL BOARD, GROUND
<FUSE>
!F600 1-532-203-00 FUSE
<FERRITE BEAD>
FB001 1-543-813-21 FERRITE 0uH
FB002 1-543-813-21 FERRITE 0uH
FB003 1-543-813-21 FERRITE 0uH
<FUSE HOLDER>
FH600 1-533-217-31 HOLDER, FUSE
FH601 1-533-217-31 HOLDER, FUSE
<IC>
IC001 8-759-526-43 IC TDA9874H/V1,118
IC031 8-759-645-07 IC LB1943N
IC101 8-759-831-27 IC HD6432197Y-PAL
(ED115/ED215/ED313/ED515/
ED616/ED815/ED817/ED818/ED915/EZ715)
IC101 8-759-831-28 IC HD6432197Y-PALG
(EXCEPT ED115/ED215/ED313/ED515/
ED616/ED815/ED817/ED818/ED915/EZ715)
IC141 8-759-580-62 IC MM1256AFBE
IC142 8-759-575-71 IC M24C04-WMN6T
IC201 8-759-589-31 IC HA118217F
IC291 8-759-566-07 IC LA7277M-TLM (ED616/ED817/
ED818/ED915/ED919/EZ717)
IC301 8-759-638-56 IC TDA9605H/N2,557
IC451 8-759-643-83 IC UPD16315GB-3BS
IC502 8-749-015-48 IC RPM6940
!IC600 8-749-018-38 IC MA8910
!IC601 8-759-420-19 IC AN1431T-TA
IC660 8-759-438-18 IC PQ12RD08
IC662 8-759-471-81 IC PQ05RD11
<CHIP CONDUCTOR>
JR001 1-216-295-00 SHORT 0
JR002 1-216-295-00 SHORT 0
JR003 1-216-295-00 SHORT 0
JR004 1-216-295-00 SHORT 0
JR005 1-216-295-00 SHORT 0
JR006 1-216-295-00 SHORT 0
JR007 1-216-295-00 SHORT 0
JR008 1-216-295-00 SHORT 0
JR009 1-216-295-00 SHORT 0
JR010 1-216-295-00 SHORT 0
JR011 1-216-295-00 SHORT 0
JR012 1-216-295-00 SHORT 0
JR013 1-216-295-00 SHORT 0
JR014 1-216-295-00 SHORT 0
JR015 1-216-295-00 SHORT 0
JR016 1-216-295-00 SHORT 0
JR017 1-216-295-00 SHORT 0
JR018 1-216-295-00 SHORT 0
JR019 1-216-295-00 SHORT 0
JR020 1-216-295-00 SHORT 0
JR021 1-216-295-00 SHORT 0
JR022 1-216-295-00 SHORT 0
JR023 1-216-295-00 SHORT 0
JR024 1-216-295-00 SHORT 0
JR025 1-216-295-00 SHORT 0
JR026 1-216-295-00 SHORT 0
JR028 1-216-295-00 SHORT 0
JR029 1-216-295-00 SHORT 0
JR030 1-216-295-00 SHORT 0
JR031 1-216-295-00 SHORT 0
JR032 1-216-295-00 SHORT 0
JR033 1-216-295-00 SHORT 0
JR034 1-216-295-00 SHORT 0
JR035 1-216-295-00 SHORT 0
JR036 1-216-295-00 SHORT 0
JR037 1-216-295-00 SHORT 0
JR038 1-216-295-00 SHORT 0
JR039 1-216-295-00 SHORT 0
JR040 1-216-295-00 SHORT 0
JR041 1-216-295-00 SHORT 0
JR042 1-216-295-00 SHORT 0
JR043 1-216-295-00 SHORT 0
JR044 1-216-295-00 SHORT 0
JR045 1-216-295-00 SHORT 0
JR046 1-216-295-00 SHORT 0
JR047 1-216-295-00 SHORT 0
JR101 1-216-296-00 SHORT 0
JR102 1-216-296-00 SHORT 0
JR103 1-216-296-00 SHORT 0
JR104 1-216-296-00 SHORT 0
JR105 1-216-296-00 SHORT 0
JR106 1-216-296-00 SHORT 0
JR107 1-216-296-00 SHORT 0
JR108 1-216-296-00 SHORT 0
JR109 1-216-296-00 SHORT 0
JR110 1-216-296-00 SHORT 0
JR111 1-216-296-00 SHORT 0
JR112 1-216-296-00 SHORT 0
JR113 1-216-296-00 SHORT 0
JR114 1-216-296-00 SHORT 0
