Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-F200/F500
7171
S834 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
< TRANSFORMER >
T801 1-445-231-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
KEY-L BOARD
***********
< CONNECTOR >
CN871 1-784-859-51 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< LED >
D871 6-501-052-02 LED CL-197HB1-D-T (AUTO) (F200)
D871 6-501-052-02 LED CL-197HB1-D-T (A.F.D STD) (F500)
D873 6-501-052-02 LED CL-197HB1-D-T (WIDE STAGE) (F200)
D873 6-501-052-02 LED CL-197HB1-D-T (D.C.S.) (F500)
< TRANSISTOR >
Q871 6-550-260-01 TRANSISTOR RT1N237M-TP-1
Q872 6-550-260-01 TRANSISTOR RT1N237M-TP-1
< RESISTOR >
R871 1-216-821-11 METAL CHIP 1K 5% 1/10W
R872 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S871 1-762-875-21 SWITCH, KEYBOARD (l/
1 )
************************************************************
KEY-R BOARD
***********
< CONNECTOR >
CN881 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< RESISTOR >
R881 1-216-821-11 METAL CHIP 1K 5% 1/10W
R882 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S881 1-762-875-21 SWITCH, KEYBOARD (VOL –)
S882 1-762-875-21 SWITCH, KEYBOARD (VOL +)
S883 1-762-875-21 SWITCH, KEYBOARD (
Z )
************************************************************
A-1497-844-A MAIN BOARD, COMPLETE (F200: AEP, UK)
A-1497-860-A MAIN BOARD, COMPLETE (F200: SP, TH)
A-1497-869-A MAIN BOARD, COMPLETE (F500: RU)
A-1497-875-A MAIN BOARD, COMPLETE (F500: CND, E3, E15,
E32, EA, MX, SP, TW, TH, AUS)
A-1498-991-A MAIN BOARD, COMPLETE (F500: KR)
********************
< LEAD >
A301 1-537-584-11 PIN, LEAD
< CAPACITOR >
C101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C104 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C201 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C202 1-128-394-11 ELECT CHIP 220uF 20% 10V
C203 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C204 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C205 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C206 1-128-394-11 ELECT CHIP 220uF 20% 10V
C207 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C208 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C209 1-128-394-11 ELECT CHIP 220uF 20% 10V
C210 1-124-779-00 ELECT CHIP 10uF 20% 16V
C211 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C212 1-124-779-00 ELECT CHIP 10uF 20% 16V
C213 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C214 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C215 1-126-193-11 ELECT CHIP 1uF 20% 50V
C216 1-124-779-00 ELECT CHIP 10uF 20% 16V
C217 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C218 1-124-779-00 ELECT CHIP 10uF 20% 16V
C219 1-126-193-11 ELECT CHIP 1uF 20% 50V
C220 1-126-193-11 ELECT CHIP 1uF 20% 50V
C221 1-126-193-11 ELECT CHIP 1uF 20% 50V
C222 1-126-193-11 ELECT CHIP 1uF 20% 50V
C223 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C224 1-128-994-21 ELECT CHIP 47uF 20% 10V
C225 1-126-193-11 ELECT CHIP 1uF 20% 50V
C226 1-126-193-11 ELECT CHIP 1uF 20% 50V
C251 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C252 1-135-474-21 ELECT CHIP 330uF 20% 6.3V
C253 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C254 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C255 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C256 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C257 1-124-779-00 ELECT CHIP 10uF 20% 16V
C258 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C259 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C260 1-117-681-11 ELECT CHIP 100uF 20% 16V
C261 1-124-779-00 ELECT CHIP 10uF 20% 16V
C262 1-126-193-11 ELECT CHIP 1uF 20% 50V
C263 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C264 1-110-530-11 ELECT CHIP 1000uF 20% 6.3V
C274 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C278 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
(F200)
C281 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
(F200)
C282 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(F200)
C301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C302 1-117-681-11 ELECT CHIP 100uF 20% 16V
C304 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(F200: AEP, UK/F500: RU, KR)
C305 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(F200: AEP, UK/F500: RU, KR)
C701 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C702 1-117-681-11 ELECT CHIP 100uF 20% 16V
C703 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C704 1-117-681-11 ELECT CHIP 100uF 20% 16V
KEY-L KEY-R MAIN
Ver. 1.1
FL
