Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WSF200/WSF500/SS-CTF500/F500/TSF200/TSF500
48
R746 1-216-809-11 METAL CHIP 100 5% 1/10W
(SA-WSF500)
R747 1-216-813-11 METAL CHIP 220 5% 1/10W
(SA-WSF500)
R748 1-216-295-91 SHORT CHIP 0 (SA-WSF500)
R750 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R751 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R752 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R753 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R754 1-216-809-11 METAL CHIP 100 5% 1/10W
(SA-WSF500)
R755 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R756 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R757 1-216-857-11 METAL CHIP 1M 5% 1/10W
(SA-WSF500)
R758 1-216-821-11 METAL CHIP 1K 5% 1/10W
(SA-WSF500)
R759 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R760 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R761 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R762 1-216-833-11 METAL CHIP 10K 5% 1/10W
(SA-WSF500)
R766 1-216-295-91 SHORT CHIP 0 (SA-WSF500)
R801 1-218-854-11 METAL CHIP 2K 0.5% 1/10W
R802 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R803 1-216-833-11 METAL CHIP 10K 5% 1/10W
R805 1-216-821-11 METAL CHIP 1K 5% 1/10W
R806 1-216-833-11 METAL CHIP 10K 5% 1/10W
R807 1-216-835-11 METAL CHIP 15K 5% 1/10W
R808 1-216-821-11 METAL CHIP 1K 5% 1/10W
R809 1-216-295-91 SHORT CHIP 0
R810 1-216-295-91 SHORT CHIP 0
R811 1-216-801-11 METAL CHIP 22 5% 1/10W
R813 1-216-801-11 METAL CHIP 22 5% 1/10W
R814 1-216-801-11 METAL CHIP 22 5% 1/10W
(SA-WSF500)
R816 1-216-864-11 SHORT CHIP 0
R817 1-216-864-11 SHORT CHIP 0
R818 1-216-864-11 SHORT CHIP 0
R819 1-216-801-11 METAL CHIP 22 5% 1/10W
R820 1-216-801-11 METAL CHIP 22 5% 1/10W
R821 1-216-864-11 SHORT CHIP 0
R822 1-216-864-11 SHORT CHIP 0
R823 1-216-821-11 METAL CHIP 1K 5% 1/10W
R824 1-216-864-11 SHORT CHIP 0
R825 1-216-805-11 METAL CHIP 47 5% 1/10W
R826 1-216-821-11 METAL CHIP 1K 5% 1/10W
R831 1-216-864-11 SHORT CHIP 0
R832 1-216-801-11 METAL CHIP 22 5% 1/10W
R833 1-216-801-11 METAL CHIP 22 5% 1/10W
R834 1-216-797-11 METAL CHIP 10 5% 1/10W
R835 1-216-864-11 SHORT CHIP 0
R836 1-216-864-11 SHORT CHIP 0
R837 1-216-857-11 METAL CHIP 1M 5% 1/10W
R838 1-216-833-11 METAL CHIP 10K 5% 1/10W
R840 1-216-833-11 METAL CHIP 10K 5% 1/10W
R841 1-216-801-11 METAL CHIP 22 5% 1/10W
R842 1-216-833-11 METAL CHIP 10K 5% 1/10W
R843 1-216-801-11 METAL CHIP 22 5% 1/10W
R845 1-216-801-11 METAL CHIP 22 5% 1/10W
R846 1-216-833-11 METAL CHIP 10K 5% 1/10W
R847 1-216-864-11 SHORT CHIP 0
R848 1-216-821-11 METAL CHIP 1K 5% 1/10W
R849 1-216-833-11 METAL CHIP 10K 5% 1/10W
R850 1-216-864-11 SHORT CHIP 0
R851 1-216-864-11 SHORT CHIP 0
R852 1-216-864-11 SHORT CHIP 0
R853 1-216-813-11 METAL CHIP 220 5% 1/10W
R861 1-216-809-11 METAL CHIP 100 5% 1/10W
R862 1-216-809-11 METAL CHIP 100 5% 1/10W
R863 1-216-809-11 METAL CHIP 100 5% 1/10W
R864 1-216-809-11 METAL CHIP 100 5% 1/10W
R865 1-216-849-11 METAL CHIP 220K 5% 1/10W
R866 1-216-821-11 METAL CHIP 1K 5% 1/10W
R867 1-216-833-11 METAL CHIP 10K 5% 1/10W
R868 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X221 1-814-108-21 VIBRATOR, CRYSTAL (49.1MHz)
X610 1-813-562-21 VIBRATOR, CERAMIC (10MHz)
X701 1-781-465-21 VIBRATOR, CRYSTAL (12.288MHz) (SA-WSF200)
X702 1-781-465-21 VIBRATOR, CRYSTAL (12.288MHz) (SA-WSF500)
X820 1-814-107-21 VIBRATOR, CRYSTAL (25MHz)
************************************************************
CONNECTOR BOARD (SA-WSF200/WSF500)
*****************
< CAPACITOR >
C001 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C002 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C003 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C004 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CN001 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN002 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< TERMINAL >
* ET001 1-780-408-11 TERMINAL
************************************************************
A-1508-660-A POWER BOARD, COMPLETE
(SA-WSF200: AEP, UK/SA-WSF500: RU)
A-1508-670-A POWER BOARD, COMPLETE
(SA-WSF500: CND, TW)
A-1508-676-A POWER BOARD, COMPLETE (SA-WSF200: SP,
TH/SA-WSF500: E3, E15, EA, SP, KR, TH, AUS)
A-1508-725-A POWER BOARD, COMPLETE (SA-WSF500: E32)
A-1508-741-A POWER BOARD, COMPLETE (SA-WSF500: MX)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
AMP-DSP CONNECTOR POWER
