Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WSF200/WSF500/SS-CTF500/F500/TSF200/TSF500
50
< FUSE >
0 F945 1-576-794-11 FUSE (2A/32V)
< FUSE HOLDER >
0 FH901 1-533-217-41 FUSE HOLDER
0 FH902 1-533-217-41 FUSE HOLDER
< FUSIBLE RESISTOR >
0 FR929 1-246-373-11 FUSIBLE 1 10% 1/2W F
< IC >
0 IC901 6-707-741-01 IC STR-F6138-LF1352
(SA-WSF500: CND, MX, TW)
0 IC901 6-707-742-01 IC STR-F6168-LF1352
(EXCEPT SA-WSF500: CND, MX, TW)
0 IC921 6-711-790-01 IC MR4020-7103
IC922 6-707-743-01 IC TA76L431S (TPE6, Q)
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-712-613-01 IC SI-3010KM-TLS
< COIL >
L931 1-457-438-11 INDUCTOR 5.6uH
L944 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L953 1-414-398-11 INDUCTOR 10uH
L954 1-457-578-11 INDUCTOR 10uH
L956 1-457-578-11 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-457-054-21 COIL, LINE FILTER
0 LF902 1-457-054-21 COIL, LINE FILTER
< PHOTO COUPLER >
0 PC901 6-600-438-01 PHOTO COUPLER TLP421F (D4-GRJ)
0 PC902 6-600-438-01 PHOTO COUPLER TLP421F (D4-GRJ)
0 PC903 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PC904 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< THERMISTOR >
PS954 1-802-595-11 THERMISTOR, POSITIVE MF-R250
PS956 1-802-596-11 THERMISTOR, POSITIVE MF-R300
< TRANSISTOR >
0 Q901 8-729-141-88 TRANSISTOR 2SB1116A-TP-LK
0 Q921 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
0 Q922 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q930 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q931 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q932 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q943 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q945 6-550-718-01 FET RSR025N03TL
Q947 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q949 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q950 8-729-038-28 TRANSISTOR RT1N441C-TP-1
< RESISTOR >
0 R901 1-219-759-91 METAL 1M 5% 1/2W F
(SA-WSF500: CND, MX, TW)
0 R901 1-240-938-91 METAL 1.5M 5% 0.5W F
(EXCEPT SA-WSF500: CND, MX, TW)
0 R903 1-215-926-51 METAL OXIDE 33K 5% 3W F
(SA-WSF500: CND, MX, TW)
0 R903 1-215-929-51 METAL OXIDE 100K 5% 3W F
(EXCEPT SA-WSF500: CND, MX, TW)
0 R904 1-215-926-51 METAL OXIDE 33K 5% 3W F
(SA-WSF500: CND, MX, TW)
0 R904 1-215-929-51 METAL OXIDE 100K 5% 3W F
(EXCEPT SA-WSF500: CND, MX, TW)
0 R905 1-216-797-91 METAL CHIP 10 5% 1/10W
0 R906 1-216-827-91 METAL CHIP 3.3K 5% 1/10W
0 R907 1-216-833-91 METAL CHIP 10K 5% 1/10W
0 R908 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R909 1-216-845-91 METAL CHIP 100K 5% 1/10W
0 R910 1-216-825-91 METAL CHIP 2.2K 5% 1/10W
0 R911 1-216-813-91 METAL CHIP 220 5% 1/10W
0 R912 1-216-361-61 METAL OXIDE 0.22 5% 2W F
(SA-WSF500: CND, MX, TW)
0 R912 1-216-363-61 METAL OXIDE 0.33 5% 2W F
(EXCEPT SA-WSF500: CND, MX, TW)
0 R913 1-216-361-61 METAL OXIDE 0.22 5% 2W F
(SA-WSF500: CND, MX, TW)
0 R914 1-220-891-11 METAL 0.1 10% 5W F
(EXCEPT SA-WSF500: CND, MX, TW)
0 R914 1-243-669-11 METAL 0.05 5% 5W F
(SA-WSF500: CND, MX, TW)
0 R916 1-215-929-51 METAL OXIDE 100K 5% 3W F
0 R917 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R919 1-216-837-91 METAL CHIP 22K 5% 1/10W
R920 1-216-821-11 METAL CHIP 1K 5% 1/10W
R921 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R922 1-244-317-71 METAL 0.18 5% 2W F
0 R923 1-218-879-91 METAL CHIP 22K 0.5% 1/10W
0 R924 1-216-837-91 METAL CHIP 22K 5% 1/10W
0 R925 1-216-797-91 METAL CHIP 10 5% 1/10W
0 R926 1-218-895-91 METAL CHIP 100K 0.5% 1/10W
0 R927 1-216-837-91 METAL CHIP 22K 5% 1/10W
0 R928 1-216-845-91 METAL CHIP 100K 5% 1/10W
0 R930 1-216-817-91 METAL CHIP 470 5% 1/10W
R931 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R932 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R933 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R938 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R939 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R940 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R941 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R942 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R945 1-216-837-11 METAL CHIP 22K 5% 1/10W
R946 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R949 1-216-809-11 METAL CHIP 100 5% 1/10W
R951 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R952 1-216-821-11 METAL CHIP 1K 5% 1/10W
R954 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R955 1-216-821-11 METAL CHIP 1K 5% 1/10W
POWER
Note: Refer to the Servicing Notes “BOND FIXATION OF
ELECTRIC PARTS” (page 4) when you exchange
LF901 and LF902.
Ver. 1.1
