133
US
Additional Information
Inputs (Digital)
Outputs
FM tuner section
Tuning range 87.5 MHz – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
AM tuner section
Antenna (aerial) Loop antenna (aerial)
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
IN 1 (DVD) (Coaxial) Impedance: 75 ohms
S/N: 96 dB (A, 20 kHz
LPF)
IN 1 (SAT/CATV), IN 2
(TV) (Optical)
S/N: 96 dB
(A, 20 kHz LPF)
VIDEO 1, ZONE 2,
(AUDIO OUT)
Voltage:150 mV
Impedance: 1 kohm
SUBWOOFER Voltage: 2 V
Impedance: 1 kohm
Tuning scale Tuning range
10 kHz step 530 kHz – 1,710 kHz
9 kHz step 531 kHz – 1,710 kHz
continued
