24
US
7 channel speaker system
• The angle A shown in the illustration
should be the same.
• If you cannot place the speakers at the
optimum angle, separate the surround
speakers and the surround back speakers
adequately and arrange them as
symmetrically as possible.
• Install the front high speakers at the same
angle as that of the front speakers. The
position should be at a height on or above an
extended diagonal line across the screen of a
TV or monitor.
6 channel speaker system
• Place the surround back speaker behind the
seating position.
Tip
Since the subwoofer does not emit highly directional
signals, you can place it wherever you want.
Recommended speaker
placement
the same angle
as that of a front
speaker
