32
US
* You can output the video game’s sound (multi-channel surround sound) from the receiver only by
connecting the video game with an HDMI cable.
** If you want to output multi-channel surround sound from the receiver, use B for the audio connection.
Notes
• When connecting optical digital cords, insert the plugs straight until they click into place.
• Do not bend or tie optical digital cords.
It is not necessary to connect all the cords. Connect cords according to the jacks of your equipment.
Video game type Required cable (cord)
Video Audio
HDMI equipped* A –
Non-HDMI equipped DB or C**
Connections required for watching programs via satellite
broadcasting or via a cable TV
Satellite tuner, Cable box with an HDMI jack
Video/audio signals
or or
Audio signals Video signals
A
BC D E
Satellite tuner, Cable box without an HDMI jack
To Next Page
