Sony STR-DA3700ES - Page 139

139
US
Additional Information
Frequency response
3)
3)
When “2ch Analog Direct” is being used.
Inputs (Analog)
Inputs (Digital)
Outputs
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
AM tuner section
Intermediate frequency
450 kHz
Antenna (aerial) Loop antenna (aerial)
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
HDMI Video
Input/Output (HDMI Repeater block)
640 × 480p @ 59.94/60 Hz
720 × 480p @ 59.94/60 Hz
1280 × 720p @ 59.94/60 Hz
1920 × 1080i @ 59.94/60 Hz
1920 × 1080p @ 59.94/60 Hz
720 × 576p @ 50 Hz
1280 × 720p @ 50 Hz
1920 × 1080i @ 50 Hz
1920 × 1080p @ 50 Hz
1280 × 720p @ 29.97/30 Hz
1920 × 1080p @ 29.97/30 Hz
1280 × 720p @ 23.98/24 Hz
1920 × 1080p @ 23.98/24 Hz
HDMI Video (3D)
Input/Output (HDMI Repeater block)
1280 × 720p @ 59.94/60 Hz
Frame Packing
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
1920 × 1080i @ 59.94/60 Hz
Frame Packing
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
1920 × 1080p @ 59.94/60 Hz
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
1280 × 720p @ 50 Hz
Frame Packing
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
1920 × 1080i @ 50 Hz
Frame Packing
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
1920 × 1080p @ 50 Hz
Side-by-Side (Half)
Over-Under (Top-and-Bottom)
SA-CD/CD, MD/TAPE,
TV, VIDEO 1/2,
BD/DVD, SAT/CATV,
GAME
10 Hz – 100 kHz
± 3 dB
SA-CD/CD, MD/TAPE,
TV, VIDEO 1/2,
BD/DVD, SAT/CATV,
GAME
Sensitivity: 150 mV
Impedance: 50 kohms
S/N: 100 dB (A,
20 kHz LPF)
IN 1 (SA-CD/CD)
(Coaxial)
Impedance: 75 ohms
S/N: 96 dB (A, 20 kHz
LPF)
IN 1 (VIDEO 1), IN 2
(TV), IN 3 (MD/TAPE)
(Optical)
S/N: 96 dB
(A, 20 kHz LPF)
MD/TAPE (REC OUT),
VIDEO 1, ZONE 2
Voltage:150 mV
Impedance: 1 kohm
SUBWOOFER Voltage: 2 V
Impedance: 1 kohm
Tuning scale Tuning range
10 kHz step 530 – 1,710 kHz
9 kHz step 531 – 1,710 kHz
continued
