42
US
The following illustration is a configuration example of a home network with the receiver, a
computer.
We recommend that you use a wired connection.
Note
Connect a router to one among ports 1 to 4 of the
receiver using only one LAN cable. Do not connect
the same router to the receiver using more than one
LAN cable. It may cause a malfunction.
Configuration example
Internet Modem
Computer
Router
LAN cable
(not supplied)
LAN cable
(not supplied)
To Next Page
