STR-DA5200ES
HARNESS SETTING
front panel block
POWER SW board
Please band together so that a ribbon cable
does not approach a primary side
of POWER SW board.
Please band the cable from a VIDEO 3 board
together in this position.
Please band together so that the ribbon cable
from a DIGITAL board cannot touch a heat sink.
DIGITAL
board
heat sink
heat sink
Please band together by purse lock
so that a cable cannot touch a heat sink.
Please band together so that a primary side
cable cannot touch a power transformer.
power
transformer
Please band together so that a cable cannot touch
a power transformer and a heat sink.
Please band together so that the ribbon cable (5pin) to AC board
and the ribbon cable (4 pin) from SP TERMNAL board
do not approach the primary side parts of AC board.
SP TERMNAL board
AC board
