Sony STR-DA5200ES Service Manual

STR-DA5200ES
19
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
Note 1: The process described in can be performed in any order.
Note 2: Without completing the process described in , the next process can not be performed.
SECTION 3
DISASSEMBLY
3-2. CASE
(Page 20)
3-4. S-VIDEO/CIS
BOARD
(Page 21)
3-3. FRONT PANEL
ASSY
(Page 20)
3-7. VIDEO BOARD
(Page 22)
3-5. TUNER
(Page 21)
3-10. DC-DC-HDMI BOARD/
POWER TRANSFORMER
(T01)
(Page 24)
3-6. E-VOLUME
BOARD
(Page 22)
SET
3-9. AUDIO BOARD
(Page 23)
3-11. MAIN BOARD
(Page 24)
3-8. ZONE3/
SP TERMINAL
BOARD
(Page 23)
