Sony STR-DA5200ES Service Manual

100
STR-DA5200ES
IC2034 PCM1609KPTR
IC2420 TC74LVX4053FT (EL)
SYSTEM
CLOCK
MANAGER
FUNCTION
CONTROL
INTERFACE
SERIAL
INPUT
INTERFACE
4X/8X
OVER SAMPLING
DIGITAL
FILTER
WITH
FUNCTION
CONTROLLER
ENHANCED
MULTI-
LEVEL
DELTA-
SIGMA
MOJULE
ZERO DETECT
DAC LPF
DAC LPF
DAC LPF
DAC LPF
DAC LPF
DAC LPF
DAC LPF
DAC LPF
RST
SCKI
SCKO
BCK
TEST
VDD
DGND
DATA1
DATA2
DATA3
ZEROA
LRCK
37
38
39
40
42
43
44
45
46
47
48
41
ZERO1/GPO1 ZERO2/GPO2 ZERO3/GPO3 ZERO4/GPO4 ZERO5/GPO5 ZERO6/GPO6
NC NC
VOUT6 VOUT5 VOUT4 VOUT3
1 2 3 4 5 6 7 8 9 10 11 12
VOUT2
VOUT1
VCOM
VOUT7
AGND5
VCC5
AGND6
VOUT8
AGND4
VCC4
AGND3
VCC3
13
14
15
16
17
18
19
20
21
22
23
24
ML MC MDI MDO
ZERO8 DATA4 ZERO7
NC VCC1 AGND1 VCC2 AGND2
36 35 34 33
3132 30
29 28 27 26 25
16 15 14 13 12 11 10 9
1 2 3 4 5 6 7 8
C
B
A
OX
IX
X-COM
Y-COM
VCC
GND
VEE
INH
OZ
Z-COM
IZ
OY
IY
C
OUT
IN
C
OUT
IN
C
OUT
IN
C
OUT
IN
C
OUT
IN
C
OUT
IN
LOGIC LEVEL CONVERTOR
IC2421 TC74VHC125FT (EKJ)
1
2
3
1A
1Y
1 OE
4
5
6
2A
2Y
2 OE
7
GND
10
9
8
3A
3Y
3 OE
13
12
11
4A
4Y
4 OE
14
VCC
