108
STR-DA5200ES
IC600 TC9274CFG-016
18 BITS
LATCH
CIRCUIT
(R-CH)
LEVEL SHIFT
&
SHIFT REGISTER
CIRCUIT
1
12
S16
13
S17
14
S18
15
GND
16
CK
17
NC
19
STB
18
DATA
20
S18
21
S17
22
S16
23
S15
24
S14
25
S13
26
S12
27
S11
28
S10
29
S9
30
S8
31
S7
32
S6
33
S5
40
VSS
41
S1
42
S2
43
S3
44
S4
39
NC
38
VDD
37
S1
36
S2
35
S3
34
S4
S5
2
S6
3
S7
4
S8
5
S9
6
S10
7
S11
8
S12
9
S13
10
S14
11
S15
18 BITS
LATCH
CIRCUIT
(L-CH)
