Sony STR-DA5200ES Service Manual

2
STR-DA5200ES
Reference Power Output at Stereo Mode
(4 ohms 1 kHz, THD
10%):
150 W + 150 W
Reference Power Output
(8 ohms 1 kHz, THD 10%)
FRONT
2)
:
150 W + 150 W
CENTER
2)
:
150 W
SURROUND
2)
:
150 W + 150 W
SURROUND BACK
2)
:
150 W + 150 W
Reference Power Output
(4 ohms 1 kHz, THD 10%)
FRONT
2)
:
150 W + 150 W
CENTER
2)
:
150 W
SURROUND
2)
:
150 W + 150 W
SURROUND BACK
2)
:
150 W + 150 W
1)
Depending on the sound field settings and the
source, there may be no sound output.
2)
Measured under the following conditions:
Power requirements: 230 V AC, 50/60 Hz
(in countries/area in Europe
other than the UK)
240 V AC, 50/60 Hz
(in the UK and general area)
AM tuner section (AEP and UK models)
Tuning range 531 − 1,602 kHz (With 9-
kHz tuning scale)
Antenna (aerial) Loop antenna (aerial)
Usable sensitivity 50 dB µ/m (at 999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity 35 dB
Frequency response
Inputs (Analog)
Inputs (Digital)
Outputs
EQUALIZER
FM tuner section
Tuning range 87.5 − 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz − 15 kHz, +0.5/−2 dB
Selectivity60 dB at 400 kHz
A
(US and Canadian models)
M tuner section
Tuning range 530 − 1,710 kHz
3)
(With
10-kHz tuning scale)
531 − 1,710 kHz
3)
(With 9-
kHz tuning scale)
Antenna (aerial) Loop antenna (aerial)
Usable sensitivity 50 dB µ/m (at 1,000 kHz or
999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity
At 9 kHz: 35 dB
At 10 kHz: 40 dB
3)
You can change the AM tuning scale to either 9
kHz or 10 kHz. After tuning in any AM station,
turn off the receiver. While holding down
TUNING MODE, press POWER on the receiver.
All preset stations will be erased when you change
the tuning scale. To reset the scale to 10 kHz (or 9
kHz), repeat the procedure.
USB section
Bit rate
AT RAC: 48 − 352 kbps (ATRAC3
plus), 66/105/132 kbps
(ATRAC3)
MP3 (MPEG 1 Audio Layer-3):
8 − 320kbps, VBR
WMA: 48 − 192 kbps, VBR
Sampling frequencies
AT RAC: 44.1 kHz
MP3 (MPEG 1 Audio Layer-3):
32/44.1/48 kHz
WMA: 44.1 kHz
PHONO RIAA equalization curve
± 0.5 dB
MULTI CHANNEL
INPUT, SA-CD/CD,
TAPE/C D-R ,
MD/DAT, DVD,
VIDEO 1/2/3
10 Hz − 100 kHz
± 3 dB
PHONO Sensitivity: 2.5mV
Impedance: 50kohms
S/N: 90dB (A, 20 kHz
LPF)
MULTI CHANNEL
INPUT, SA-CD/CD,
TAPE/CD-R, MD/DAT,
DVD, TV/SAT,
VIDEO1/2/3
Sensitivity: 150mV
Impedance: 50kohms
S/N: 100dB (A, 20 kHz
LPF)
DVD, TAPE/CD-R,
SA-CD/CD (Coaxial)
Impedance: 75ohms
S/N: 96dB (A, 20 kHz
LPF)
VIDEO 1/2/3, TV/SAT,
MD/DAT (Optical)
S/N: 96 dB
(A, 20 kHz LPF)
TAPE/CD-R, MD/DAT
(REC OUT),
VIDEO1/2 (AUDIO OUT)
Vo l tage:150mV
Impedance: 1kohms
FRONT L/R, CENTER,
SURROUND L/R,
SURROUND BACK L/R,
SUB WOOFER
Vo l tage: 2V
Impedance: 1kohms
Gain levels ±10 dB, 1 dB step
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
S video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B
/C
B
: 0.7 Vp-p, 75 ohms
P
R
/C
R
: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
General (US and Canadian models)
Power requirements 120 V AC, 60 Hz
Power consumption 480 W/580 VA (US/
Canada)
Power consumption (during standby mode)
1 W
AC outlets 2 switched, 100 W/0.8 A
MA
X
Dimensions 430 × 175 × 430 mm
(width/height/depth)
including projecting parts
and controls
Mass (Approx.) 15.5 kg (34 lb 3 oz)
Supplied accessories
Operating Instructions
Quick Setup Guide (1)
Optimizer microphone ECM-AC1 (1)
FM wire antenna (aerial) (1)
AM loop antenna (aerial) (1)
AC power cord (mains lead) (1)
Remote commander RM-AAL005 (1)
(US and Canadian models)
Remote commander RM-AAU009 (1)
R6 (size-AA) batteries (4)
Design and specifications are subject to
change without notice.
General (AEP and UK models)
Power requirements 230 V AC, 50/60 Hz
(in countries/area in
Europe other than UK)
240 V AC, 50/60 Hz
(in UK and general area)
Power consumption 480 W
Power consumption (during standby mode)
1 W
AC outlets 1 switched, 100 W MA
X
(Models for countries/
areas in Europe other than
the UK.)
Dimensions 430 × 175 × 430 mm
(width/height/depth)
including projecting parts
and controls
Mass (Approx.) 15.5 kg
Remote commander RM-AAL006 (1)
(AEP and UK models)
