27
STR-DA5200ES
Display
DSP Ver S: ***, P: XXX
FL**** FR XXXX
SL**** SR XXXX
CT**** SW XXXX
SBL**** SBR XXXX
DAC MUTE U XXXXXXXX
DAC MUTE L XXXXXXXX
EEPROM [****] FR XX
SUPER RESET [XXX]
2nd VOLUME XXX
DARK OUT DUTY [XXX%]
STOP CLK [XX] [XX] [XX]
Remark
***: DSP decoder patch version
XXX: DSP post process version
****: Front L-ch volume value
XXXX: Front R-ch volume value
****: Surround L-ch volume value
XXXX: Surround R-ch volume value
****: Center volume value
XXXX: Sub woofer R-ch volume value
****: Surround back L-ch volume value
XXXX: Surround back R-ch volume value
Display of module information to demand muting in system controller (for
design evaluation)
Display of module information to demand muting in system controller (for
design evaluation)
****: EEPROM address
XX: EEPROM data (switching with M m button of the remote commander)
Not used for the servicing
If super reset is performed, “up convert signal level adjustment” will also be
initialized
When EEPROM initialization is required, perform the “all clear mode”
XXX: 2nd room volume value (00 to ∞)
XXX: Duty value of FL display (0% to 100%)
(switching with M m button of the remote commander)
Value of register related to clock of system controller display mode (for
design evaluation)
Items
DSP Version display
Volume value display (FL/FR)
Volume value display (SL/SR)
Volume value display (CT/SW)
Volume value display
(SBL/SBR)
DAC mute information disclosure
1
DAC mute information disclosure
2
EERROM debug
Super reset
2nd volume value display
FL display duty change
Stop clock
To Next Page
