– 5 –
SECTION 3
DIAGRAMS
3-1. CIRCUIT BOARDS LOCATION
SURR board
S VIDEO board
STANDBY (2) board
DISPLAY board
AMP board
INPUT board
SP board
CONNECTOR board
H.P board
STANDBY board
BALANCE board
VIDEO boar
d
FUNCTION board
SW board
VIDEO (3) board
SP SWITCH
board
VOLUME board
REAR AMP board
