– 51 –
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
SECTION 5
ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
AMP
* A-4414-175-A AMP BOARD, COMPLETE (DB825)
********************
* A-4417-193-A AMP BOARD, COMPLETE (DB725)
********************
< CAPACITOR >
C501 1-126-965-11 ELECT 22uF 20% 50V
C520 1-126-967-11 ELECT 47uF 20% 50V
C521 1-107-597-11 CERAMIC 22PF 10% 500V
C522 1-107-597-11 CERAMIC 22PF 10% 500V
C523 1-162-286-31 CERAMIC 220PF 10% 50V
C524 1-126-964-11 ELECT 10uF 20% 50V
C525 1-136-157-00 FILM 0.022uF 5% 50V
C526 1-136-153-00 FILM 0.01uF 5% 50V
C570 1-126-967-11 ELECT 47uF 20% 50V
C571 1-107-597-11 CERAMIC 22PF 10% 500V
C572 1-107-597-11 CERAMIC 22PF 10% 500V
C573 1-162-286-31 CERAMIC 220PF 10% 50V
C574 1-126-964-11 ELECT 10uF 20% 50V
C575 1-136-157-00 FILM 0.022uF 5% 50V
C576 1-136-153-00 FILM 0.01uF 5% 50V
C590 1-126-935-11 ELECT 470uF 20% 6.3V
C620 1-126-967-11 ELECT 47uF 20% 50V
C621 1-107-597-11 CERAMIC 22PF 10% 500V
C622 1-107-597-11 CERAMIC 22PF 10% 500V
C623 1-162-286-31 CERAMIC 220PF 10% 50V
C625 1-136-157-00 FILM 0.022uF 5% 50V
C801 1-126-967-11 ELECT 47uF 20% 50V
C803 1-117-950-11 ELECT 10000uF 20% 63V
C804 1-117-950-11 ELECT 10000uF 20% 63V
C805 1-130-781-00 FILM 0.22uF 10% 100V
C806 1-130-781-00 FILM 0.22uF 10% 100V
C811 1-126-952-11 ELECT 1000uF 20% 35V
C812 1-126-951-11 ELECT 470uF 20% 35V
C813 1-126-967-11 ELECT 47uF 20% 50V
C817 1-126-967-11 ELECT 47uF 20% 50V
C818 1-126-967-11 ELECT 47uF 20% 50V
CC48 1-136-153-00 CERAMIC 5% 50V
CC49 1-136-153-00 CERAMIC 5% 50V
CC98 1-136-153-00 CERAMIC 5% 50V
CC99 1-136-153-00 CERAMIC 5% 50V
< CONNECTOR >
* CND805 1-564-341-11 PIN, CONNECTOR 7P
CNS651 1-784-806-11 HOUSING, CONNECTOR (PC BOARD) 13P
CNS804 1-568-439-11 SOCKET, CONNECTOR 7P
* CNV801 1-564-243-11 PIN, CONNECTOR 6P
* CNV802 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P
< DIODE >
D501 8-719-911-19 DIODE 1SS119-25
D502 8-719-109-51 DIODE RD2.0ES-B2
D503 8-719-109-51 DIODE RD2.0ES-B2
D504 8-719-911-19 DIODE 1SS119-25
D505 8-719-911-19 DIODE 1SS119-25
D506 8-719-911-19 DIODE 1SS119-25
D545 8-719-911-19 DIODE 1SS119-25
D546 8-719-911-19 DIODE 1SS119-25
D547 8-719-911-19 DIODE 1SS119-25
D548 8-719-911-19 DIODE 1SS119-25
D549 8-719-911-19 DIODE 1SS119-25
D551 8-719-911-19 DIODE 1SS119-25
D552 8-719-109-51 DIODE RD2.0ES-B2
D553 8-719-109-51 DIODE RD2.0ES-B2
D554 8-719-911-19 DIODE 1SS119-25
D555 8-719-911-19 DIODE 1SS119-25
D556 8-719-911-19 DIODE 1SS119-25
D601 8-719-911-19 DIODE 1SS119-25
D602 8-719-109-51 DIODE RD2.0ES-B2
D603 8-719-109-51 DIODE RD2.0ES-B2
D604 8-719-911-19 DIODE 1SS119-25
D608 8-719-911-19 DIODE 1SS119-25
D801 8-719-302-38 DIODE RBV-602-01
D802 8-719-200-82 DIODE 11ES2
D803 8-719-200-82 DIODE 11ES2
D804 8-719-200-82 DIODE 11ES2
D805 8-719-200-82 DIODE 11ES2
D806 8-719-068-24 DIODE HZ5.6BP-TK
D807 8-719-934-21 DIODE HZS30-1L
< GROUND TERMINAL >
* EB702 1-537-738-21 TERMINAL, EARTH
* EB703 1-537-738-21 TERMINAL, EARTH
< FUSE, FUSE HOLDER >
! F801 1-532-506-51 FUSE (T6.3AL/250V)
F801 1-533-223-11 HOLDER, FUSE
! F802 1-532-506-51 FUSE (T6.3AL/250V)
F802 1-533-223-11 HOLDER, FUSE
! F803 1-532-504-51 FUSE (T4AL/250V)
F803 1-533-223-11 HOLDER, FUSE
! F804 1-532-504-51 FUSE (T4AL/250V)
F804 1-533-223-11 HOLDER, FUSE
To Next Page
