– 52 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< IC >
IC809 8-759-708-05 IC NJM78L05A
< COIL >
L501 1-411-906-11 COIL, AIR-CORE
L551 1-411-906-11 COIL, AIR-CORE
< TRANSISTOR >
Q504 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q505 8-729-209-15 TRANSISTOR 2SD2012
Q506 8-749-010-25 IC MN2488-OPY-M
Q507 8-749-010-26 IC MP1620-OPY-M
Q508 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q509 8-729-281-53 TRANSISTOR 2SC1815-GR
Q510 8-729-900-63 TRANSISTOR DTA124ES
Q511 8-729-900-63 TRANSISTOR DTA124ES
Q546 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q547 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q548 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q549 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q554 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q555 8-729-209-15 TRANSISTOR 2SD2012
Q556 8-749-010-25 IC MN2488-OPY-M
Q557 8-749-010-26 IC MP1620-OPY-M
Q558 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q559 8-729-281-53 TRANSISTOR 2SC1815-GR
Q560 8-729-900-63 TRANSISTOR DTA124ES
Q561 8-729-900-63 TRANSISTOR DTA124ES
Q596 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q601 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q605 8-729-209-15 TRANSISTOR 2SD2012
Q606 8-749-010-25 IC MN2488-OPY-M
Q607 8-749-010-26 IC MP1620-OPY-M
Q608 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q613 8-729-281-53 TRANSISTOR 2SC1815-GR
Q616 8-729-900-36 TRANSISTOR DTC124ES
Q801 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R501 1-249-432-11 CARBON 18K 5% 1/4W
R502 1-249-421-11 CARBON 2.2K 5% 1/4W F
R503 1-249-432-11 CARBON 18K 5% 1/4W
R504 1-249-429-11 CARBON 10K 5% 1/4W
! R505 1-249-405-11 CARBON 100 5% 1/4W F
! R506 1-249-381-11 CARBON 1 5% 1/4W F
R521 1-249-429-11 CARBON 10K 5% 1/4W
R522 1-249-437-11 CARBON 47K 5% 1/4W F
R523 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R524 1-249-408-11 CARBON 180 5% 1/4W F
! R525 1-249-408-11 CARBON 180 5% 1/4W F
! R526 1-233-352-41 ENCAPSULATED COMPONENT
R527 1-247-850-11 CARBON 6.2K 5% 1/4W
R528 1-249-417-11 CARBON 1K 5% 1/4W F
R529 1-247-866-11 CARBON 30K 5% 1/4W
R530 1-249-422-11 CARBON 2.7K 5% 1/4W F
R531 1-249-433-11 CARBON 22K 5% 1/4W
R532 1-249-437-11 CARBON 47K 5% 1/4W
! R533 1-249-393-11 CARBON 10 5% 1/4W F
! R534 1-249-389-11 CARBON 4.7 5% 1/4W F
R535 1-249-431-11 CARBON 15K 5% 1/4W
R539 1-249-427-11 CARBON 6.8K 5% 1/4W F
R540 1-249-417-11 CARBON 1K 5% 1/4W F
R542 1-249-429-11 CARBON 10K 5% 1/4W
R547 1-249-425-11 CARBON 4.7K 5% 1/4W F
R548 1-249-429-11 CARBON 10K 5% 1/4W
! R549 1-249-393-11 CARBON 10 5% 1/4W F
R551 1-247-881-00 CARBON 120K 5% 1/4W
R552 1-247-881-00 CARBON 120K 5% 1/4W
R571 1-249-429-11 CARBON 10K 5% 1/4W
R572 1-249-437-11 CARBON 47K 5% 1/4W F
R573 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R574 1-249-408-11 CARBON 180 5% 1/4W F
! R575 1-249-408-11 CARBON 180 5% 1/4W F
! R576 1-233-352-41 ENCAPSULATED COMPONENT
R577 1-247-850-11 CARBON 6.2K 5% 1/4W
R578 1-249-417-11 CARBON 1K 5% 1/4W F
R579 1-247-866-11 CARBON 30K 5% 1/4W
R580 1-249-422-11 CARBON 2.7K 5% 1/4W F
R581 1-249-433-11 CARBON 22K 5% 1/4W
R582 1-249-437-11 CARBON 47K 5% 1/4W
! R583 1-249-393-11 CARBON 10 5% 1/4W F
! R584 1-249-389-11 CARBON 4.7 5% 1/4W F
R585 1-249-431-11 CARBON 15K 5% 1/4W
R586 1-249-429-11 CARBON 10K 5% 1/4W
R587 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R588 1-249-393-11 CARBON 10 5% 1/4W F
R589 1-249-432-11 CARBON 18K 5% 1/4W
R590 1-249-432-11 CARBON 18K 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
! R606 1-249-393-11 CARBON 10 5% 1/4W F
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-247-881-00 CARBON 120K 5% 1/4W
R623 1-249-421-11 CARBON 2.2K 5% 1/4W F
! R624 1-249-408-11 CARBON 180 5% 1/4W F
! R625 1-249-408-11 CARBON 180 5% 1/4W F
! R626 1-233-352-41 ENCAPSULATED COMPONENT
R627 1-247-850-11 CARBON 6.2K 5% 1/4W
R628 1-249-417-11 CARBON 1K 5% 1/4W F
R632 1-249-437-11 CARBON 47K 5% 1/4W
! R633 1-249-393-11 CARBON 10 5% 1/4W F
! R642 1-215-890-11 METAL OXIDE 470 5% 2W F
R643 1-249-441-11 CARBON 100K 5% 1/4W F
R650 1-249-425-11 CARBON 4.7K 5% 1/4W F
R672 1-249-437-11 CARBON 47K 5% 1/4W F
! R739 1-215-868-00 METAL OXIDE 680 5% 1W F
! R789 1-215-868-00 METAL OXIDE 680 5% 1W F
! R802 1-249-401-11 CARBON 47 5% 1/4W F
R803 1-247-843-11 CARBON 3.3K 5% 1/4W
! RR48 1-249-393-11 CARBON 10 5% 1/4W F
! RR49 1-249-393-11 CARBON 10 5% 1/4W F
! RR98 1-249-393-11 CARBON 10 5% 1/4W F
! RR99 1-249-393-11 CARBON 10 5% 1/4W F
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
AMP
