BALANCE DISPLAY
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< RELAY >
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V)
RY602 1-515-793-11 RELAY
< TERMINAL >
TM501 1-694-429-21 TERMINAL BOARD (SP)(SPEAKERS FRONT A/B)
**************************************************************
* 1-670-096-11 BALANCE BOARD
**************
< CONNECTOR >
* CNS105 1-564-521-11 PLUG, CONNECTOR 6P
< VARIABLE RESISTOR >
RV402 1-225-650-11 RES, VAR, CARBON 100K/100K
**************************************************************
* 1-669-441-11 CONNECTOR BOARD
*****************
< CONNECTOR >
CNP207 1-784-807-11 CONNECTOR, BOARD TO BOARD 13P
CNP651 1-784-807-11 CONNECTOR, BOARD TO BOARD 13P
**************************************************************
* A-4414-144-A DISPLAY BOARD, COMPLETE (DB725)
***********************
* A-4414-171-A DISPLAY BOARD, COMPLETE (DB825)
***********************
* 3-386-245-11 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C101 1-164-159-11 CERAMIC 0.1uF 50V
C102 1-164-159-11 CERAMIC 0.1uF 50V
C103 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-126-959-11 ELECT 0.47uF 20% 50V
C105 1-164-159-11 CERAMIC 0.1uF 50V
C106 1-162-306-11 CERAMIC 0.01uF 20% 16V
C107 1-162-306-11 CERAMIC 0.01uF 20% 16V
C109 1-124-589-11 ELECT 47uF 20% 16V
(DB825)
C110 1-164-159-11 CERAMIC 0.1uF 50V
(DB825)
C111 1-124-589-11 ELECT 47uF 20% 16V
C112 1-126-960-11 ELECT 1uF 20% 50V
(DB825)
C113 1-124-589-11 ELECT 47uF 20% 16V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-104-905-11 CAPACITOR 0.22F 5.5V
C116 1-164-159-11 CERAMIC 0.1uF 50V
C117 1-164-159-11 CERAMIC 0.1uF 50V
C130 1-164-159-11 CERAMIC 0.1uF 50V
C131 1-162-306-11 CERAMIC 0.01uF 20% 16V
(DB825)
C132 1-162-306-11 CERAMIC 0.01uF 20% 16V
(DB825)
C143 1-164-159-11 CERAMIC 0.1uF 50V
C1107 1-124-589-11 ELECT 47uF 20% 16V
< CONNECTOR >
* CND101 1-564-496-11 PIN, CONNECTOR 3P
* CND103 1-564-500-11 PIN, CONNECTOR 7P
CND104 1-564-501-11 PIN, CONNECTOR 8P
* CNE102 1-564-519-11 PLUG, CONNECTOR 4P
CNP103 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
CNP107 1-779-365-11 CONNECTOR, PC BOARD (PLUG) 8P
CNP119 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
CNS102 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
* CNS116 1-568-856-11 SOCKET, CONNECTOR 13P
* CNS117 1-568-858-11 SOCKET, CONNECTOR 15P
< DIODE >
D101 8-719-059-14 DIODE SID313BP-TP19 (DB825)
D102 8-719-059-14 DIODE SID313BP-TP19 (DB825)
D103 8-719-059-14 DIODE SID313BP-TP19 (DB825)
D104 8-719-911-19 DIODE 1SS119-25
D105 8-719-911-19 DIODE 1SS119-25 (DB825)
D106 8-719-911-19 DIODE 1SS119-25 (DB825)
D107 8-719-911-19 DIODE 1SS119-25
D108 8-719-911-19 DIODE 1SS119-25
D111 8-719-058-64 DIODE SEL5823A-TP15 (TONE)
D117 8-719-911-19 DIODE 1SS119-25
D119 8-719-911-19 DIODE 1SS119-25
D120 8-719-911-19 DIODE 1SS119-25
D121 8-719-911-19 DIODE 1SS119-25
D124 8-719-313-45 DIODE SEL6810A-TH10 (TUNER)
D125 8-719-313-45 DIODE SEL6810A-TH10 (VIDEO 1)
D126 8-719-313-45 DIODE SEL6810A-TH10 (PHONO)
D127 8-719-313-45 DIODE SEL6810A-TH10 (TAPE/MD)
D128 8-719-313-45 DIODE SEL6810A-TH10 (TV/LD)
D129 8-719-313-45 DIODE SEL6810A-TH10 (VIDEO 2)
D130 8-719-313-45 DIODE SEL6810A-TH10 (CD)
D131 8-719-313-45 DIODE SEL6810A-TH10 (VIDEO 3)
D135 8-719-058-64 DIODE SEL5823A-TP15 (5.1/DVD INPUT)
D136 8-719-058-64 DIODE SEL5823A-TP15 (BASS BOOST)
D151 8-719-911-19 DIODE 1SS119-25
D152 8-719-911-19 DIODE 1SS119-25
D153 8-719-911-19 DIODE 1SS119-25
D154 8-719-911-19 DIODE 1SS119-25
D184 8-719-911-19 DIODE 1SS119-25
D1101 8-719-911-19 DIODE 1SS119-25
< FLUORESCENT INDICATOR >
FL101 1-517-770-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC101 8-759-459-83 IC NJL55H400A
IC102 8-759-545-07 IC TMP87C447U-4A06 (DB825)
IC103 8-759-540-93 IC uPD780208GF-023-3BA (DB825)
IC106 8-759-962-08 IC BA6208
CONNECTORAMP
