Sony STR-DB798 Operating Instructions

Getting Started
masterpage:Right
lename[E:\SEM_Janet\Revision
D
ata\J9051275_2598516131DB798CEL\2598516131\GB03CON_STR-DB798-CEL.fm]
15
GB
model name1[STR-DB798]
[2-598-516-13(1)]
Required cords
A Speaker cords (not supplied)
(+)
B Monaural audio cord (not supplied)
Black
(–)
1)
If you have an additional front speaker system, connect them to the SPEAKERS FRONT B terminals. You can
select the front speakers you want to use with SPEAKERS (OFF/A/B/A+B) button. For details, see “Selecting the
speaker system” (page 46).
2)
If you connect only one surround back speaker, connect it to the SPEAKERS SURR BACK L terminals.
3)
Except for models of area code CEK.
4)
Except for models of area code TW (Taiwan). For details, see “Connecting the AC power cord” on page 16.
SUB WOOFER
RLRL
R
RL
CENTER
~ AC IN
FRONT
A
AUDIO OUT
IMPEDANCE SELECTOR
4
8
Ee
AA
Ee
A
Ee
A
Ee
SPEAKERS
FRONT B
1)
IMPEDANCE
SELECTOR
3)
AC IN
4)
E e
A
E e
A
INPUT
AUDIO
IN
B
E e
A
FRONT
B
L
SPEAKERS
SURR
BACK
SURR
Surround speaker
(Right)
Surround speaker
(Left)
Sub woofer
Surround back
speaker (Right)
2)
Surround back
speaker (Left)
2)
Center speaker
Front speaker
(Left)
Front speaker
(Right)
GB01COV_STR-DB798-CEL.book Page 15 Thursday, August 18, 2005 8:59 AM

Sony STR-DB798 Specifications

General

Impedance	8 Ω
Supported radio bands	FM
Radio Data System (RDS)	Yes
Channels quantity	7 channels
I/O ports	Output(Component x 1, Optical Digital x 1, Composite x 1, S-Video x 1), Input(Component x 2, Optical Digital x 4, S-Video x 4, Coaxial Digital x 2, Composite x 4)
