Additional Information
Receiver
A.F.D. qj (32, 34)
Cover ws (63)
DIRECT qs (30)
DISPLAY 9 (26, 27, 59)
Display 7 (28)
INPUT MODE q; (37)
INPUT SELECTOR qf (22, 23,
25, 30, 37, 41, 44, 59)
IR (receptor) 1 (48, 60)
MAIN MENU 4 (17, 38, 39, 44)
MASTER VOLUME –/+ qa (16,
20, 22, 58)
MEMORY/ENTER 5 (16, 17,
25, 44)
MENU 3 (17, 38, 39, 44)
MOVIE qh (33, 34, 59)
MULTI CHANNEL DECODING
(indicator) 8 (23)
MULTI CH IN qd (23)
MUSIC qg (34, 59)
PHONES (jack) wg (22, 58)
PRESET TUNING –/+ wa (25)
PUSH wf (63)
SPEAKERS (OFF/A/B/A+B) wh
(15, 46, 58)
SURR BACK DECODING ql
(35)
TUNING –/+ w; (23)
VIDEO 3 INPUT (jacks) wd (6, 7)
2CH qk (30, 34, 39)
–/+ 6 (17, 38, 40, 44)
?/1 (power) 2 (16, 17, 24, 39,
60)
List of button locations and reference pages
How to use this page
Use this page to find the location of buttons and other
parts of the receiver that are mentioned in the text.
Ill
us
t
ra
ti
on num
b
er
r
DISPLAY 9 (26, 27, 59)
RR
Name of button/part Reference page
ALPHABETICAL ORDER
A - L
M - Z
NUMBERS AND SYMBOLS
P
U
S
H
263
0
8745
9
1
wawfwgwh
wd
ws
w;
qk qj qh qg qf qd qsql
qa
To remove the cover
Press PUSH to remove the cover. When you remove the
cover, keep the cover out of reach of the children.
