Sony STR-DB798 Operating Instructions

Additional Information
masterpage:Right
lename[E:\SEM_Janet\Revision
D
ata\J9051275_2598516131DB798CEL\2598516131\GB09ADD_STR-DB798-CEL.fm]
61
GB
model name1[STR-DB798]
[2-598-516-13(1)]
Amplifier section
Power Output
Models of area code CEL, CEK, TW
Rated Power Output at Stereo Mode
(8 ohms 20 Hz – 20 kHz, THD 0.09%)
100 W + 100 W
1)
(8 ohms 1 kHz, THD 0.7%)
110 W + 110 W
1)
(8 ohms 1 kHz, THD 10%)
135 W + 135 W
1)
Reference Power Output
1)
(8 ohms 20 Hz – 20 kHz, THD 0.09%)
FRONT
2)
: 100 W/ch
CENTER
2)
: 100 W
SURR
2)
: 100 W/ch
SURR BACK
2)
: 100 W/ch
(8 ohms 1 kHz, THD 0.7%)
FRONT
2)
: 110 W/ch
CENTER
2)
: 110 W
SURR
2)
: 110 W/ch
SURR BACK
2)
: 110 W/ch
(8 ohms 1 kHz, THD 10%)
FRONT
2)
: 135 W/ch
CENTER
2)
: 135 W
SURR
2)
: 135 W/ch
SURR BACK
2)
: 135 W/ch
1) Measured under the following conditions:
2) Depending on the sound field settings and the
source, there may be no sound output.
Frequency response
Inputs (Analog)
3) INPUT SHORT.
4) Weighted network, input level.
Inputs (Digital)
Outputs (Analog)
Outputs (Digital)
Equalizer
Specifications
Area code Power requirements
CEL, CEK 230 V AC, 50 Hz
TW 110 V AC, 60 Hz
PHONO RIAA equalization curve
±0.5 dB
MULTI CH IN, SA-CD/
CD, MD/TAPE, DVD,
TV/SAT, VIDEO 1, 2, 3
10 Hz – 100 kHz
+0.5/–2 dB (when
ANALOG DIRECT is
selected)
PHONO Sensitivity: 2.5 mV
Impedance: 50 k ohms
S/N
3)
: 86 dB
(A, 2.5 mV
4)
)
MULTI CH IN, SA-CD/
CD, MD/TAPE, DVD,
TV/SAT, VIDEO 1, 2, 3
Sensitivity: 150 mV
Impedance: 50 k ohms
S/N
3)
: 96 dB
(A, 150 mV
4)
)
DVD, SA-CD/CD
(Coaxial)
Sensitivity: –
Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
DVD, TV/SAT,
MD/TAPE, VIDEO 3
(Optical)
Sensitivity: –
Impedance: –
S/N: 100 dB
(A, 20 kHz LPF)
MD/TAPE (OUT),
VIDEO 1, 2
(AUDIO OUT)
Voltage: 150 mV
Impedance: 2.2 k ohms
SUB WOOFER Voltage: 2 V
Impedance: 1 k ohm
MD/TAPE (Optical) Sensitivity: –
Gain levels ±10 dB, 1 dB step
continued
GB01COV_STR-DB798-CEL.book Page 61 Thursday, August 18, 2005 8:59 AM

Sony STR-DB798 Specifications

General

Impedance	8 Ω
Supported radio bands	FM
Radio Data System (RDS)	Yes
Channels quantity	7 channels
I/O ports	Output(Component x 1, Optical Digital x 1, Composite x 1, S-Video x 1), Input(Component x 2, Optical Digital x 4, S-Video x 4, Coaxial Digital x 2, Composite x 4)
