Sony STR-DE185 - Main Section Transistors and Resistors

28
STR-DE185
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC904 8-759-701-75 IC NJM7805FA (AEP,UK)
< JACK >
J801 1-774-411-11 JACK, PIN 6P (CD,MD/TAPE)
J802 1-793-776-12 JACK, PIN 6P (VIDEO 2,VIDEO 1)
< COIL >
L701 1-422-009-13 COIL, AIR-CORE
L751 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q424 8-729-900-36 TRANSISTOR DTC124ES
Q474 8-729-900-36 TRANSISTOR DTC124ES
Q680 8-729-900-63 TRANSISTOR DTA124ES
Q681 8-729-900-36 TRANSISTOR DTC124ES
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q702 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q705 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q706 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q752 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q755 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q756 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q781 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q782 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q783 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q784 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q785 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q786 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q902 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q903 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q904 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R401 1-249-425-11 CARBON 4.7K 5% 1/4W
R402 1-249-425-11 CARBON 4.7K 5% 1/4W
R403 1-249-421-11 CARBON 2.2K 5% 1/4W
R404 1-249-425-11 CARBON 4.7K 5% 1/4W
R405 1-249-425-11 CARBON 4.7K 5% 1/4W
R406 1-249-425-11 CARBON 4.7K 5% 1/4W
R407 1-249-425-11 CARBON 4.7K 5% 1/4W
R408 1-249-425-11 CARBON 4.7K 5% 1/4W
R409 1-249-421-11 CARBON 2.2K 5% 1/4W
R410 1-249-421-11 CARBON 2.2K 5% 1/4W
R411 1-249-425-11 CARBON 4.7K 5% 1/4W
R412 1-249-425-11 CARBON 4.7K 5% 1/4W
R413 1-247-843-11 CARBON 3.3K 5% 1/4W
R414 1-247-843-11 CARBON 3.3K 5% 1/4W
R415 1-249-417-11 CARBON 1K 5% 1/4W
R416 1-249-437-11 CARBON 47K 5% 1/4W
R417 1-249-433-11 CARBON 22K 5% 1/4W
R418 1-249-433-11 CARBON 22K 5% 1/4W
R421 1-249-437-11 CARBON 47K 5% 1/4W
R422 1-249-433-11 CARBON 22K 5% 1/4W
R423 1-249-433-11 CARBON 22K 5% 1/4W
R424 1-249-429-11 CARBON 10K 5% 1/4W
R425 1-249-425-11 CARBON 4.7K 5% 1/4W
R426 1-249-425-11 CARBON 4.7K 5% 1/4W
R427 1-249-441-11 CARBON 100K 5% 1/4W
R428 1-249-441-11 CARBON 100K 5% 1/4W
R451 1-249-425-11 CARBON 4.7K 5% 1/4W
R452 1-249-425-11 CARBON 4.7K 5% 1/4W
R453 1-249-421-11 CARBON 2.2K 5% 1/4W
R454 1-249-425-11 CARBON 4.7K 5% 1/4W
R455 1-249-425-11 CARBON 4.7K 5% 1/4W
R456 1-249-425-11 CARBON 4.7K 5% 1/4W
R457 1-249-425-11 CARBON 4.7K 5% 1/4W
R458 1-249-425-11 CARBON 4.7K 5% 1/4W
R459 1-249-421-11 CARBON 2.2K 5% 1/4W
R460 1-249-421-11 CARBON 2.2K 5% 1/4W
R461 1-249-425-11 CARBON 4.7K 5% 1/4W
R462 1-249-425-11 CARBON 4.7K 5% 1/4W
R463 1-247-843-11 CARBON 3.3K 5% 1/4W
R464 1-247-843-11 CARBON 3.3K 5% 1/4W
R465 1-249-417-11 CARBON 1K 5% 1/4W
R466 1-249-437-11 CARBON 47K 5% 1/4W
R467 1-249-433-11 CARBON 22K 5% 1/4W
R468 1-249-433-11 CARBON 22K 5% 1/4W
R471 1-249-437-11 CARBON 47K 5% 1/4W
R472 1-249-433-11 CARBON 22K 5% 1/4W
R473 1-249-433-11 CARBON 22K 5% 1/4W
R474 1-249-429-11 CARBON 10K 5% 1/4W
R475 1-249-425-11 CARBON 4.7K 5% 1/4W
R476 1-249-425-11 CARBON 4.7K 5% 1/4W
R477 1-249-441-11 CARBON 100K 5% 1/4W
R478 1-249-441-11 CARBON 100K 5% 1/4W
R481 1-247-807-31 CARBON 100 5% 1/4W
R482 1-247-807-31 CARBON 100 5% 1/4W
R483 1-247-807-31 CARBON 100 5% 1/4W
R484 1-247-807-31 CARBON 100 5% 1/4W
R485 1-247-807-31 CARBON 100 5% 1/4W
R602 1-249-439-11 CARBON 68K 5% 1/4W
R603 1-249-439-11 CARBON 68K 5% 1/4W
R604 1-249-411-11 CARBON 330 5% 1/4W
R605 1-249-417-11 CARBON 1K 5% 1/4W
R652 1-249-439-11 CARBON 68K 5% 1/4W
R653 1-249-439-11 CARBON 68K 5% 1/4W
R654 1-249-411-11 CARBON 330 5% 1/4W
R655 1-249-417-11 CARBON 1K 5% 1/4W
R681 1-249-437-11 CARBON 47K 5% 1/4W
R697 1-249-433-11 CARBON 22K 5% 1/4W
R701 1-249-421-11 CARBON 2.2K 5% 1/4W
R702 1-249-440-11 CARBON 82K 5% 1/4W
R703 1-249-414-11 CARBON 560 5% 1/4W
MAIN
