Sony STR-DE185 - Outlet, Relay, and Transformer Parts

29
STR-DE185
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R704 1-249-408-11 CARBON 180 5% 1/4W
R705 1-249-408-11 CARBON 180 5% 1/4W
R706 1-233-352-41 COMPONENT, ENCAPSULATED 0.22X2
R707 1-249-425-11 CARBON 4.7K 5% 1/4W
R708 1-240-855-11 CARBON 6.2K 5% 1/4W
R709 1-249-419-11 CARBON 1.5K 5% 1/4W
R710 1-247-881-00 CARBON 120K 5% 1/4W
R711 1-249-431-11 CARBON 15K 5% 1/4W
R712 1-249-393-11 CARBON 10 5% 1/4W
R713 1-249-437-11 CARBON 47K 5% 1/4W
R714 1-249-389-11 CARBON 4.7 5% 1/4W
R751 1-249-421-11 CARBON 2.2K 5% 1/4W
R752 1-249-440-11 CARBON 82K 5% 1/4W
R753 1-249-414-11 CARBON 560 5% 1/4W
R754 1-249-408-11 CARBON 180 5% 1/4W
R755 1-249-408-11 CARBON 180 5% 1/4W
R756 1-233-352-41 COMPONENT, ENCAPSULATED 0.22X2
R757 1-249-425-11 CARBON 4.7K 5% 1/4W
R758 1-240-855-11 CARBON 6.2K 5% 1/4W
R759 1-249-419-11 CARBON 1.5K 5% 1/4W
R760 1-247-881-00 CARBON 120K 5% 1/4W
R761 1-249-431-11 CARBON 15K 5% 1/4W
R762 1-249-393-11 CARBON 10 5% 1/4W
R763 1-249-437-11 CARBON 47K 5% 1/4W
R764 1-249-389-11 CARBON 4.7 5% 1/4W
R781 1-249-425-11 CARBON 4.7K 5% 1/4W
R782 1-249-425-11 CARBON 4.7K 5% 1/4W
R783 1-249-425-11 CARBON 4.7K 5% 1/4W
R784 1-249-401-11 CARBON 47 5% 1/4W
R785 1-249-401-11 CARBON 47 5% 1/4W
R786 1-249-425-11 CARBON 4.7K 5% 1/4W
R787 1-249-425-11 CARBON 4.7K 5% 1/4W
R788 1-249-427-11 CARBON 6.8K 5% 1/4W
R789 1-249-437-11 CARBON 47K 5% 1/4W
R790 1-249-417-11 CARBON 1K 5% 1/4W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W F
0 R793 1-215-868-00 METAL OXIDE 680 5% 1W F
R794 1-249-429-11 CARBON 10K 5% 1/4W
R795 1-249-401-11 CARBON 47 5% 1/4W
R901 1-249-425-11 CARBON 4.7K 5% 1/4W
R902 1-249-381-11 CARBON 1 5% 1/4W
0 R903 1-219-237-11 SOLID 3.3M 20% 1/2W F
(US)
R904 1-249-435-11 CARBON 33K 5% 1/4W
R905 1-249-433-11 CARBON 22K 5% 1/4W
R906 1-249-421-11 CARBON 2.2K 5% 1/4W
R907 1-249-428-11 CARBON 8.2K 5% 1/4W
R908 1-249-422-11 CARBON 2.7K 5% 1/4W
R909 1-249-431-11 CARBON 15K 5% 1/4W
R910 1-249-429-11 CARBON 10K 5% 1/4W
R911 1-247-843-11 CARBON 3.3K 5% 1/4W
R912 1-249-417-11 CARBON 1K 5% 1/4W
R913 1-249-401-11 CARBON 47 5% 1/4W
R914 1-249-425-11 CARBON 4.7K 5% 1/4W
0 R915 1-240-877-11 FUSIBLE 0.15 5% 1/2W F
R916 1-249-389-11 CARBON 4.7 5% 1/4W
R917 1-249-429-11 CARBON 10K 5% 1/4W
R919 1-249-439-11 CARBON 68K 5% 1/4W
R920 1-249-439-11 CARBON 68K 5% 1/4W
R921 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK)
R922 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK)
R923 1-249-429-11 CARBON 10K 5% 1/4W
R924 1-247-807-31 CARBON 100 5% 1/4W
R925 1-247-807-31 CARBON 100 5% 1/4W
R926 1-247-791-11 CARBON 22 5% 1/4W
R929 1-249-381-11 CARBON 1 5% 1/4W
R930 1-249-381-11 CARBON 1 5% 1/4W
RR701 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
RR702 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
RR751 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
RR752 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK)
< RELAY >
RY781 1-755-421-11 RELAY (12V)
RY782 1-755-421-11 RELAY (12V)
RY783 1-755-421-11 RELAY (12V)
RY981 1-755-013-11 RELAY (12V)
0 RY982 1-755-334-11 RELAY, AC POWER (9V)
< TRANSFORMER >
0 T902 1-435-435-11 TRANSFORMER, POWER (AEP,UK)
0 T902 1-435-436-11 TRANSFORMER, POWER (US)
< TERMINAL BOARD >
TM801 1-537-376-11 TERMINAL BOARD (SPEAKERS)
*************************************************************
1-683-818-11 OUTLET BOARD
*************
< AC OUTLET >
0 CNJ901 1-785-285-11 OUTLET, AC (1P) (AC OUTLET) (AEP,UK)
0 CNJ901 1-785-834-11 OUTLET, AC (1P) (AC OUTLET) (US)
< CONNECTOR >
CNP907 1-564-321-00 PIN, CONNECTOR 2P
*************************************************************
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
MAIN OUTLET
