Sony STR-DE185 - Power SW, Accessories, and Miscellaneous Parts

30
STR-DE185
Ref. No. Part No. Description Remark
1-683-817-11 POWER SW BOARD
****************
< DIODE >
D205 8-719-046-39 LED SEL5821A-TP15 (SPEAKERS A)
D206 8-719-046-39 LED SEL5821A-TP15 (SPEAKERS B)
< TRANSISTOR >
Q204 8-729-900-36 TRANSISTOR DTC124ES
Q205 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R289 1-249-409-11 CARBON 220 5% 1/4W
R290 1-249-409-11 CARBON 220 5% 1/4W
R297 1-249-417-11 CARBON 1K 5% 1/4W
< SWITCH >
S201 1-771-410-21 SWITCH, TACTILE (?/1)
S202 1-771-410-21 SWITCH, TACTILE (SPEAKERS A)
S203 1-771-410-21 SWITCH, TACTILE (SPEAKERS B)
*************************************************************
MISCELLANEOUS
***************
57 1-765-332-11 WIRE (FLAT TYPE) (15 CORE)
59 1-773-054-11 WIRE (FLAT TYPE) (17 CORE) (US)
59 1-773-125-11 WIRE (FLAT TYPE) (19 CORE) (AEP,UK)
0 105 1-769-744-11 CORD, POWER (AEP,UK)
0 105 1-783-820-11 CORD, POWER (US)
109 1-769-943-11 WIRE (FLAT TYPE) (11 CORE) (US)
109 1-773-007-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK)
0 F901 1-532-464-31 FUSE (T2.5A/250V) (AEP,UK)
0 F901 1-576-109-11 FUSE (5A/125V) (US)
0 F902 1-532-464-31 FUSE (T2.5A/250V) (AEP,UK)
0 F902 1-576-109-11 FUSE (5A/125V) (US)
Q703 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q704 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q753 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q754 8-749-010-26 TRANSISTOR MP1620-OPY-M
0 T901 1-437-625-11 TRANSFORMER, POWER (US)
0 T901 1-437-626-11 TRANSFORMER, POWER (AEP,UK)
TM301 1-693-533-11 TUNER (FM/AM) (ANTENNA) (AEP,UK)
TM301 1-693-534-71 TUNER (FM/AM) (ANTENNA) (US)
************************************************************
ACCESSORIES
************
1-477-133-11 REMOTE COMMANDER (RM-U185)
1-501-374-11 ANTENNA, LOOP (AM)
1-501-594-11 ANTENNA (FM) (AEP,UK)
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
1-793-184-21 CONNECTOR (F TYPE ADAPTOR) (FM ANTENNA)
(US)
4-228-696-01 COVER, BATTERY (for RM-U185)
4-238-304-11 MANUAL, INSTRUCTION (ENGLISH)
4-238-304-21 MANUAL, INSTRUCTION (FRENCH,DUTCH,
SWEDISH,GERMAN,SPANISH,
ITALIAN,POLISH) (AEP)
4-238-304-31 MANUAL, INSTRUCTION (DANISH,FINNISH)
(AEP)
4-238-304-41 MANUAL, INSTRUCTION (PORTUGUESE) (AEP)
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
POWER SW
