50
STR-DE495/DE595
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R717 1-249-393-11 CARBON 10 5% 1/4W
R718 1-249-389-11 CARBON 4.7 5% 1/4W
R719 1-249-425-11 CARBON 4.7K 5% 1/4W
R721 1-247-850-11 CARBON 6.2K 5% 1/4W
R722 1-249-419-11 CARBON 1.5K 5% 1/4W
R723 1-249-437-11 CARBON 47K 5% 1/4W
R724 1-249-431-11 CARBON 15K 5% 1/4W
R725 1-249-439-11 CARBON 68K 5% 1/4W
R731 1-249-425-11 CARBON 4.7K 5% 1/4W
R732 1-249-381-11 CARBON 1 5% 1/4W
R733 1-249-381-11 CARBON 1 5% 1/4W
R734 1-249-404-81 CARBON 82 5% 1/4W
R735 1-249-427-11 CARBON 6.8K 5% 1/4W
R736 1-249-417-11 CARBON 1K 5% 1/4W
R737 1-249-436-11 CARBON 39K 5% 1/4W
R740 1-249-433-11 CARBON 22K 5% 1/4W
R742 1-249-437-11 CARBON 47K 5% 1/4W
R743 1-249-433-11 CARBON 22K 5% 1/4W
R744 1-249-433-11 CARBON 22K 5% 1/4W
R745 1-249-433-11 CARBON 22K 5% 1/4W
R746 1-249-433-11 CARBON 22K 5% 1/4W
R747 1-249-431-11 CARBON 15K 5% 1/4W
R748 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE495)
R748 1-249-427-11 CARBON 6.8K 5% 1/4W
(DE595)
R750 1-249-433-11 CARBON 22K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-421-11 CARBON 2.2K 5% 1/4W
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-249-433-11 CARBON 22K 5% 1/4W
R756 1-249-433-11 CARBON 22K 5% 1/4W
R757 1-249-431-11 CARBON 15K 5% 1/4W
R758 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE495)
R758 1-249-427-11 CARBON 6.8K 5% 1/4W
(DE595)
R760 1-249-421-11 CARBON 2.2K 5% 1/4W
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W
R764 1-249-405-11 CARBON 100 5% 1/4W
R765 1-249-405-11 CARBON 100 5% 1/4W
R766 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R767 1-249-393-11 CARBON 10 5% 1/4W
R768 1-249-389-11 CARBON 4.7 5% 1/4W
R769 1-249-425-11 CARBON 4.7K 5% 1/4W
R770 1-249-437-11 CARBON 47K 5% 1/4W
R771 1-247-850-11 CARBON 6.2K 5% 1/4W
R772 1-249-419-11 CARBON 1.5K 5% 1/4W
R773 1-249-437-11 CARBON 47K 5% 1/4W
R775 1-249-439-11 CARBON 68K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R780 1-249-429-11 CARBON 10K 5% 1/4W
R791 1-249-425-11 CARBON 4.7K 5% 1/4W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W F
R793 1-249-404-81 CARBON 82 5% 1/4W
0 R794 1-215-868-00 METAL OXIDE 680 5% 1W F
R802 1-249-404-81 CARBON 82 5% 1/4W
R803 1-249-389-11 CARBON 4.7 5% 1/4W
R804 1-249-426-11 CARBON 5.6K 5% 1/4W
R806 1-249-433-11 CARBON 22K 5% 1/4W
R851 1-249-404-81 CARBON 82 5% 1/4W
(DE595)
R852 1-249-425-11 CARBON 4.7K 5% 1/4W
(DE595)
0 R910 1-243-635-11 FUSIBLE 0.33 5% 1/2W F
RR11 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK,AUS,KR,TW)
RR12 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK,AUS,KR,TW)
RR13 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK,AUS,KR,TW)
RR14 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK,AUS,KR,TW)
RR15 1-249-393-11 CARBON 10 5% 1/4W
(AEP,UK,AUS,KR,TW)
RR16 1-249-393-11 CARBON 10 5% 1/4W
(DE595:AEP,UK,AUS,KR,TW)
RR17 1-249-393-11 CARBON 10 5% 1/4W
(DE595:AEP,UK,AUS,KR,TW)
< RELAY >
RY501 1-515-921-11 RELAY (12V)
RY560 1-755-267-11 RELAY
RY601 1-515-921-11 RELAY (12V)
RY701 1-515-921-11 RELAY (12V)
RY791 1-515-921-11 RELAY (12V)
RY851 1-515-921-11 RELAY (12V) (DE595)
< TERMINAL >
TM601 1-694-805-11 TERMINAL BOARD (SPEAKERS
SURROUND,CENTER)
TM602 1-694-785-11 TERMINAL BOARD (SPEAKERS FRONT) (DE495)
TM602 1-694-785-11 TERMINAL BOARD (SPEAKERS FRONT A)
(DE595)
TM603 1-694-785-11 TERMINAL BOARD (SPEAKERS FRONT B)
(DE595)
*************************************************************
POWER BOARD
*************
< CONNECTOR >
* CNP102 1-564-518-11 PLUG, CONNECTOR 3P
< SWITCH >
S151 1-771-410-21 SWITCH, TACTILE (SPEAKERS) (DE595)
S152 1-771-410-21 SWITCH, TACTILE (?/1)
*************************************************************
1-686-904-11 STANDBY BOARD
**************
1-533-293-11 HOLDER, FUSE
< CAPACITOR >
C813 1-164-159-11 CERAMIC 0.1uF 50V
C814 1-164-159-11 CERAMIC 0.1uF 50V
C815 1-126-943-11 ELECT 2200uF 20% 25V
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
MAIN STANDBYPOWER
Ver 1.1
