Sony STR-DE495 - Page 51

51
STR-DE495/DE595
C816 1-126-942-61 ELECT 1000uF 20% 25V
C920 1-164-159-11 CERAMIC 0.1uF 50V
C921 1-164-159-11 CERAMIC 0.1uF 50V
C923 1-126-959-11 ELECT 0.47uF 20% 50V
C950 1-126-936-11 ELECT 3300uF 20% 16V
< CONNECTOR >
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP902 1-580-843-11 PIN, CONNECTOR (POWER) 2P
CNP903 1-564-506-11 PLUG, CONNECTOR 3P
CNP905 1-779-495-11 PLUG, CONNECTOR 4P
CNP906 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P (E2)
CNP912 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D820 8-719-024-99 DIODE 11ES2-NTA2B
D821 8-719-024-99 DIODE 11ES2-NTA2B
D822 8-719-024-99 DIODE 11ES2-NTA2B
D823 8-719-024-99 DIODE 11ES2-NTA2B
D901 8-719-911-19 DIODE 1SS119-25
D910 8-719-024-99 DIODE 11ES2-NTA2B
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-024-99 DIODE 11ES2-NTA2B
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-911-19 DIODE 1SS119-25
D915 8-719-911-19 DIODE 1SS119-25
< EARTH TERMINAL >
* G901 1-537-738-21 TERMINAL, EARTH (US,CND)
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q921 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
0 R810 1-243-634-11 FUSIBLE 0.22 5% 1/2W F
0 R812 1-243-634-11 FUSIBLE 0.22 5% 1/2W F
0 R901 1-219-237-11 SOLID 3.3M 20% 1/2W F
(US,CND)
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W
R904 1-249-381-11 CARBON 1 5% 1/4W
R921 1-249-437-11 CARBON 47K 5% 1/4W
R922 1-249-435-11 CARBON 33K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-298-11 RELAY
< VOLTAGE SELECTOR >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E2)
< TRANSFORMER >
0 T902 1-435-281-11 TRANSFORMER, POWER (US,CND,MX)
0 T902 1-435-434-11 TRANSFORMER, POWER (E2)
0 T902 1-435-435-11 TRANSFORMER, POWER
(AEP,UK,AUS,SP,MY,AR,KR)
0 T902 1-435-563-11 TRANSFORMER, POWER (TW)
*************************************************************
A-4731-175-A VIDEO BOARD, COMPLETE
(DE495,DE595:AEP,UK)
1-686-905-11 VIDEO BOARD (EXCEPT DE495,DE595:AEP,UK)
************
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-934-11 ELECT 220uF 20% 10V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C301 1-126-935-11 ELECT 470uF 20% 10V
(EXCEPT DE495,DE595:AEP,UK)
C302 1-126-935-11 ELECT 470uF 20% 10V
(EXCEPT DE495,DE595:AEP,UK)
C303 1-126-935-11 ELECT 470uF 20% 10V
(EXCEPT DE495,DE595:AEP,UK)
C308 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE495,DE595:AEP,UK)
C309 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE495,DE595:AEP,UK)
C310 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE495,DE595:AEP,UK)
C311 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE495,DE595:AEP,UK)
C312 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE495,DE595:AEP,UK)
C313 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DE495,DE595:AEP,UK)
C317 1-126-947-11 ELECT 47uF 20% 25V
(EXCEPT DE495,DE595:AEP,UK)
C329 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT DE495,DE595:AEP,UK)
C330 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT DE495,DE595:AEP,UK)
C331 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT DE495,DE595:AEP,UK)
C332 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT DE495,DE595:AEP,UK)
C338 1-126-947-11 ELECT 47uF 20% 25V
(EXCEPT DE495,DE595:AEP,UK)
C809 1-126-934-11 ELECT 220uF 20% 10V
C824 1-164-159-11 CERAMIC 0.1uF 50V
C825 1-164-159-11 CERAMIC 0.1uF 50V
C827 1-126-947-11 ELECT 47uF 20% 25V
< CONNECTOR >
CNP156 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS250 1-569-315-11 SOCKET, CONNECTOR 5P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STANDBY
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
VIDEO
Ver 1.1
