52
STR-DE495/DE595
< DIODE >
D203 8-719-911-19 DIODE 1SS119-25
D204 8-719-911-19 DIODE 1SS119-25
< IC >
IC203 6-701-890-01 IC NJM2595D
IC301 8-759-231-66 IC TC74HC4053AP
(EXCEPT DE495,DE595:AEP,UK)
IC302 6-701-891-01 IC NJM2581D (EXCEPT DE495,DE595:AEP,UK)
IC804 8-759-701-65 IC NJM79M05FA
IC807 8-759-231-53 IC TA7805S
< JACK >
J200 1-794-978-11 JACK, PIN 3P (DVD VIDEO IN,
VIDEO 2 VIDEO IN,VIDEO 1 VIDEO OUT)
J201 1-815-043-11 JACK, PIN 2P (VIDEO 1 VIDEO IN,
MONITOR VIDEO OUT)
J301 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO
DVD IN,VIDEO 2 IN,MONITOR OUT)
(EXCEPT DE495,DE595:AEP,UK)
< TRANSISTOR >
Q301 8-729-116-02 TRANSISTOR BA1A4M-TP
(EXCEPT DE495,DE595:AEP,UK)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R301 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R302 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R303 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R304 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R305 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R306 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R307 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R308 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R309 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R310 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R311 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R312 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R313 1-249-433-11 CARBON 22K 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R325 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
R347 1-247-807-31 CARBON 100 5% 1/4W
(EXCEPT DE495,DE595:AEP,UK)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
VIDEO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
VOL
VOL BOARD
**********
< CONNECTOR >
* CNP104 1-564-518-11 PLUG, CONNECTOR 3P
< ROTARY ENCODER >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
*************************************************************
MISCELLANEOUS
***************
58 1-773-154-11 WIRE (FLAT TYPE) (21 CORE)
0 103 1-696-847-11 CORD, POWER (AUS)
0 103 1-769-079-22 CORD, POWER (KR)
0 103 1-777-071-23 CORD, POWER (AEP,UK,E2,SP,MY)
0 103 1-783-532-11 CORD, POWER (US,CND,MX,TW)
0 103 1-783-941-12 CORD, POWER (AR)
105 1-769-937-11 WIRE (FLAT TYPE) (11 CORE) (EXCEPT AEP,UK)
105 1-773-001-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK)
106 1-575-662-31 WIRE (FLAT TYPE) (5 CORE)
0 F901 1-532-464-31 FUSE (T2.5AL/250V) (EXCEPT US,CND,MX,TW)
0 F901 1-576-109-11 FUSE (5A/125V) (DE495:TW)
0 F901 1-576-193-11 FUSE (6.3A/125V) (DE595:US,CND,MX,TW)
Q503 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q504 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q603 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q604 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q653 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q654 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q703 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q704 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q753 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q754 8-749-010-26 TRANSISTOR MP1620-OPY-M
0 T901 1-437-996-11 TRANSFORMER, POWER
(DE495:AEP,UK,KR,SP,MY)
0 T901 1-437-999-11 TRANSFORMER, POWER (DE495:AUS)
0 T901 1-439-549-11 TRANSFORMER, POWER (DE595:US,MX)
0 T901 1-439-550-11 TRANSFORMER, POWER
(DE595:AEP,UK,AUS,AR,KR)
0 T901 1-439-551-11 TRANSFORMER, POWER (DE595:SP,MY)
0 T901 1-439-552-11 TRANSFORMER, POWER (DE595:TW)
0 T901 1-439-553-11 TRANSFORMER, POWER (DE595:E2)
0 T901 1-439-609-11 TRANSFORMER, POWER (DE595:CND)
0 T901 1-439-640-11 TRANSFORMER, POWER (DE495:TW)
TM301 1-693-577-22 TUNER PACK (ANTENNA) (US,CND,E2,MX,AR)
TM301 1-693-578-22 TUNER PACK (ANTENNA) (AEP,UK)
TM301 1-693-580-22 TUNER PACK (ANTENNA) (AUS,SP,MY,KR,TW)
*************************************************************
Ver 1.1
