Sony STR-DE845 - Chassis and Internal Components

57
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
(2) CHASSIS SECTION-1
#1
#1
#1
66
not
supplied
#1
#1
#4
#1
#1
#1
#1
#2
#2
#1
#1
#1
#1
#1
#1
not
supplied
not
supplied
not
supplied
T901
not
supplied
57
57
57
57
61
65
64
62
55
59
59
53
60
53
60
51
52
54
not supplied
not supplied
CH
US, CND
E, PX
E, SP
DE945
AUS
B
B
B
B
B
56
51 1-677-002-11 H.P BOARD
52 1-676-988-11 DC (1) BOARD
53 4-985-642-01 CUSHION
54 1-676-989-11 DC (2) BOARD
55 1-773-150-11 WIRE (FLAT TYPE) (21 CORE) (160mm)
* 56 3-703-244-00 BUSHING (2104), CORD
0 57 1-696-847-11 CORD, POWER (AUS)
0 57 1-769-743-11 CORD, POWER (CND)
0 57 1-769-744-11 CORD, POWER (E, PX)
0 57 1-782-464-21 CORD, POWER (CH)
0 57 1-783-820-11 CORD, POWER (US)
59 X-4947-208-1 FOOT ASSY (F50150S) (BLACK)
(US, CND, E, AUS, PX)
59 X-4952-298-1 FOOT ASSY (F50150S) (GOLD) (MY, SP, CH)
60 4-977-358-11 CUSHION
0 61 1-569-008-21 ADAPTOR, CONVERSION 2P (E, PX)
62 1-773-004-11 WIRE (FLAT TYPE) (15 CORE) (100mm)
64 1-773-001-11 WIRE (FLAT TYPE) (15 CORE) (70mm)
65 A-4428-787-A DIGITAL BOARD, COMPLETE
(DE845: US, CND)
65 A-4428-801-A DIGITAL BOARD, COMPLETE
(EXCEPT US, CND)
65 A-4428-820-A DIGITAL BOARD, COMPLETE (DE945)
66 1-677-003-11 VIDEO 3 BOARD (DE945)
0 T901 1-435-428-11 TRANSFORMER, POWER (E, PX)
0 T901 1-435-429-11 TRANSFORMER, POWER (AUS)
0 T901 1-435-430-11 TRANSFORMER, POWER (US)
0 T901 1-435-431-11 TRANSFORMER, POWER (CND)
0 T901 1-435-432-11 TRANSFORMER, POWER (MY, SP, CH)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
