63
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
DIGITAL
C1221 1-126-964-11 ELECT 10uF 20% 50V
C1222 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1223 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1224 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1225 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1226 1-126-960-11 ELECT 1uF 20% 50V
C1228 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C1229 1-126-935-11 ELECT 470uF 20% 16V
C1230 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1231 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1232 1-126-935-11 ELECT 470uF 20% 16V
C1233 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C1234 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C1235 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C1236 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1237 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1238 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1239 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1301 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1302 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C1303 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1304 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1305 1-104-664-11 ELECT 47uF 20% 16V
C1306 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C1307 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1309 1-126-934-11 ELECT 220uF 20% 10V
C1310 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1311 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1312 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1313 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1314 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1315 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C1401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1402 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1403 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1404 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1405 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1406 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1407 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1408 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1409 1-104-664-11 ELECT 47uF 20% 16V
C1410 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1411 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1412 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1413 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1414 1-104-664-11 ELECT 47uF 20% 16V
C1416 1-104-664-11 ELECT 47uF 20% 16V
C1417 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1501 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1502 1-126-935-11 ELECT 470uF 20% 16V
C1506 1-126-964-11 ELECT 10uF 20% 50V
C1508 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1509 1-104-664-11 ELECT 47uF 20% 16V
C1513 1-126-964-11 ELECT 10uF 20% 50V
C1514 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1515 1-126-964-11 ELECT 10uF 20% 50V
C1516 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1518 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1519 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C1522 1-126-965-11 ELECT 22uF 20% 50V
C1523 1-106-347-00 MYLAR 1500PF 5% 200V
C1544 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1570 1-126-964-11 ELECT 10uF 20% 50V
C1571 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1572 1-126-965-11 ELECT 22uF 20% 50V
C1573 1-106-347-00 MYLAR 1500PF 5% 200V
C3118 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C3119 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
< CONNECTOR >
CNP4 1-784-923-11 PIN, CONNECTOR 7P
CNP7 1-784-927-11 PIN, CONNECTOR 12P
CNS1 1-784-776-11 CONNECTOR, FFC 15P
CNS2 1-784-778-11 CONNECTOR, FFC 17P (E, AUS, CH, PX)
CNS2 1-784-782-11 CONNECTOR, FFC 21P (DE845: US, CND)
CNS5 1-784-782-11 CONNECTOR, FFC 21P
CNS6 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D1001 8-719-016-74 DIODE 1SS352-TPH3
D1101 8-719-016-74 DIODE 1SS352-TPH3
D1201 8-719-016-74 DIODE 1SS352-TPH3
D1202 8-719-016-74 DIODE 1SS352-TPH3
D1203 8-719-016-74 DIODE 1SS352-TPH3
D1204 8-719-801-78 DIODE 1SS184-TE85L
D1205 8-719-801-78 DIODE 1SS184-TE85L
D1206 8-719-016-74 DIODE 1SS352-TPH3
D1207 8-719-016-74 DIODE 1SS352-TPH3
D1208 8-719-053-18 DIODE 1SR154-400TE-25
D1209 8-719-801-78 DIODE 1SS184-TE85L
D1210 8-719-016-74 DIODE 1SS352-TPH3
D1211 8-719-053-18 DIODE 1SR154-400TE-25
D1212 8-719-016-74 DIODE 1SS352-TPH3
< FERRITE BEAD >
FB1101 1-469-152-11 FERRITE, EMI (SMD)
FB1102 1-469-152-11 FERRITE, EMI (SMD)
FB1103 1-469-152-11 FERRITE, EMI (SMD)
FB1104 1-414-598-11 INDUCTOR, FERRITE BEAD
FB1105 1-414-598-11 INDUCTOR, FERRITE BEAD
FB1301 1-469-152-11 FERRITE, EMI (SMD)
FB1302 1-469-152-11 FERRITE, EMI (SMD)
FB1401 1-469-152-11 FERRITE, EMI (SMD)
FB1402 1-414-598-11 INDUCTOR, FERRITE BEAD
FB1403 1-414-598-11 INDUCTOR, FERRITE BEAD
FB1404 1-414-598-11 INDUCTOR, FERRITE BEAD
FB1405 1-469-152-11 FERRITE, EMI (SMD)
FB1501 1-469-152-11 FERRITE, EMI (SMD)
FB1502 1-469-152-11 FERRITE, EMI (SMD)
< IC >
IC1001 8-749-017-36 IC TORX-179 (DVD/LD IN)
IC1002 8-749-923-05 IC TORX178A (TV/SAT IN)
IC1003 8-749-923-05 IC TORX178A (MD/DAT IN)
IC1004 8-749-923-04 IC TOTX178A (MD/DAT OUT)
IC1005 8-759-595-15 IC TC74ACT153AF (EL)
