64
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
DIGITAL
IC1007 8-759-242-70 IC TC7WU04F (TE12R)
IC1101 8-759-639-35 IC LC89055W-RA8
IC1201 8-759-680-64 IC MB90573PFV-G-296-BND
IC1202 8-759-186-30 IC TC74VHC14F (EL)
IC1203 8-759-445-59 IC BA033T
IC1204 8-759-231-53 IC M5F7805L
IC1205 8-759-231-53 IC M5F7805L
IC1206 8-759-544-04 IC NJM2103M-TE2
IC1207 8-759-231-53 IC M5F7805L
IC1208 8-759-231-53 IC M5F7805L
IC1301 8-759-643-42 IC CXD9511AQ
IC1401 8-752-391-87 IC CXD2712R
IC1402 8-759-538-16 IC IDT71V016S15PH-AUTL
IC1403 8-759-524-32 IC TC74VHC367FT (EL)
IC1404 8-759-242-70 IC TC7WU04F (TE12R)
IC1501 8-759-231-53 IC M5F7805L
IC1503 8-759-657-47 IC AK4527
IC1504 8-759-099-06 IC M5218AFP-TE1
IC1511 8-759-231-58 IC M5F7812L
IC1554 8-759-099-06 IC M5218AFP-TE1
< JACK >
J1001 1-778-228-11 JACK, PIN 1P (COAX)
< SHORT >
JR1001 1-216-296-00 SHORT 0
JR1002 1-216-296-00 SHORT 0
JR1003 1-216-296-00 SHORT 0
JR1004 1-216-296-00 SHORT 0
JR1005 1-216-296-00 SHORT 0
JR1006 1-216-296-00 SHORT 0
JR1007 1-216-295-00 SHORT 0
JR1008 1-216-295-00 SHORT 0
JR1009 1-216-296-00 SHORT 0
< TRANSISTOR >
Q1201 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q1202 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q1203 8-729-027-43 TRANSISTOR RT1N141C-TP-1
Q1204 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q1205 8-729-048-78 TRANSISTOR 2SD1733-TL-QR
< RESISTOR >
R1001 1-216-025-00 RES-CHIP 100 5% 1/10W
R1002 1-216-025-00 RES-CHIP 100 5% 1/10W
R1003 1-216-025-00 RES-CHIP 100 5% 1/10W
R1004 1-216-025-00 RES-CHIP 100 5% 1/10W
R1006 1-216-025-00 RES-CHIP 100 5% 1/10W
R1007 1-216-025-00 RES-CHIP 100 5% 1/10W
R1008 1-216-022-00 METAL CHIP 75 5% 1/10W
R1009 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1010 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1011 1-216-025-00 RES-CHIP 100 5% 1/10W
R1013 1-216-115-00 METAL CHIP 560K 5% 1/10W
R1101 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1102 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1104 1-216-022-00 METAL CHIP 75 5% 1/10W
R1105 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
R1106 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R1108 1-216-025-00 RES-CHIP 100 5% 1/10W
R1110 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1111 1-216-121-00 RES-CHIP 1M 5% 1/10W
R1112 1-216-295-00 SHORT 0
R1114 1-216-025-00 RES-CHIP 100 5% 1/10W
R1115 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1131 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
R1160 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1192 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1201 1-216-097-00 RES-CHIP 100K 5% 1/10W
R1202 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1203 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1204 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1205 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1206 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1207 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1208 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1209 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1210 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1211 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1212 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1213 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1214 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1215 1-216-025-00 RES-CHIP 100 5% 1/10W
R1216 1-216-025-00 RES-CHIP 100 5% 1/10W
R1217 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1218 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1219 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1220 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1221 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE845)
R1222 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE945)
R1223 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE845)
R1224 1-216-089-00 RES-CHIP 47K 5% 1/10W
R1225 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R1226 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R1227 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE945)
R1228 1-216-075-00 METAL CHIP 12K 5% 1/10W
R1229 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1230 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1232 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1233 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1234 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1235 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1236 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1237 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1238 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R1239 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1240 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1241 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1242 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1243 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1244 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1245 1-216-049-11 RES-CHIP 1K 5% 1/10W
