STR-DG910
Pin No. Pin Name I/O Pin Description
72 IOGND — Ground
73 CGND — Ground
74 CVCC18 — Power supply terminal (+1.8 V)
75 to 79 D4 to D0 I Serial data input 4 to 0 from HDMI RX and video processor.
80 DE I Data enable signal input from HDMI RX.
