Sony STR-DH540 User Manual

76
GB
Reference sections
Specifications
AUDIO POWER
SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
(USA model only)
With 6 ohm loads, both channels driven,
from 20 – 20,000 Hz; rated 90 watts per
channel minimum RMS power, with no
more than 0.09% total harmonic distortion
from 250 milliwatts to rated output.
Amplifier section
Power Output
1)
Minimum RMS Output Power
(6 ohms, 20 Hz – 20 kHz, THD 0.09%)
90 W + 90 W
Stereo Mode Output Power
(6 ohms, 1 kHz, THD 1%)
105 W + 105 W
Surround Mode Output Power
2)
(6 ohms, 1 kHz, THD 0.9%)
145 W per channel
1)
Measured under the following conditions:
2)
Reference power output for front, center and
surround speakers. Depending on the sound
field settings and the source, there may be no
sound output.
Frequency response
Analog
10 Hz – 100 kHz, +0.5/–2 dB (with
sound field and equalizer bypassed)
Input
Analog
Sensitivity: 500 mV/50 kilohms
S/N
3)
: 105 dB (A, 500 mV
4)
)
Clearing the memory
To clear See
All memorized settings page 52
Customized sound fields page 46
Area Power requirements
USA, Canada 120 V AC, 60 Hz
Europe,
Australia
230 V AC, 50 Hz

Sony STR-DH540 Specifications

General

Receiver type	-
Audio output channels	5.2 channels
Total Harmonic Distortion (THD)	0.5 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	4
Audio (L/R) in	2
Digital audio coaxial in	1
Connectivity technology	Wired
Ethernet LAN	No
Auto digital tuning	Yes
Supported radio bands	AM, FM
Preset stations quantity	30
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.3 W

Weight and Dimensions

Depth	329.4 mm
Width	430 mm
Height	156 mm
Weight	7700 g
