Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
37
STR-K650P
MAIN
0 R715 1-249-405-11 CARBON 100 5% 1/4W F
0 R716 1-234-182-11 ENCAPSULATED COMPONENT
0 R717 1-249-393-11 CARBON 10 5% 1/4W F
0 R718 1-249-389-11 CARBON 4.7 5% 1/4W F
R719 1-249-425-11 CARBON 4.7K 5% 1/4W F
R721 1-247-850-11 CARBON 6.2K 5% 1/4W
R722 1-249-419-11 CARBON 1.5K 5% 1/4W F
R723 1-249-437-11 CARBON 47K 5% 1/4W
R724 1-249-431-11 CARBON 15K 5% 1/4W
R725 1-249-439-11 CARBON 68K 5% 1/4W
R731 1-249-425-11 CARBON 4.7K 5% 1/4W F
0 R732 1-249-381-11 CARBON 1 5% 1/4W F
0 R733 1-249-381-11 CARBON 1 5% 1/4W F
0 R734 1-249-404-00 CARBON 82 5% 1/4W F
R735 1-249-427-11 CARBON 6.8K 5% 1/4W F
R736 1-249-417-11 CARBON 1K 5% 1/4W F
R737 1-249-436-11 CARBON 39K 5% 1/4W
R740 1-249-433-11 CARBON 22K 5% 1/4W
R742 1-249-437-11 CARBON 47K 5% 1/4W
R743 1-249-433-11 CARBON 22K 5% 1/4W
R744 1-249-433-11 CARBON 22K 5% 1/4W
R745 1-249-433-11 CARBON 22K 5% 1/4W
R746 1-249-433-11 CARBON 22K 5% 1/4W
R747 1-249-431-11 CARBON 15K 5% 1/4W
R748 1-247-843-11 CARBON 3.3K 5% 1/4W
R750 1-249-433-11 CARBON 22K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-421-11 CARBON 2.2K 5% 1/4W F
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-249-433-11 CARBON 22K 5% 1/4W
R756 1-249-433-11 CARBON 22K 5% 1/4W
R757 1-249-431-11 CARBON 15K 5% 1/4W
R758 1-247-843-11 CARBON 3.3K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W F
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W F
0 R764 1-249-405-11 CARBON 100 5% 1/4W F
0 R765 1-249-405-11 CARBON 100 5% 1/4W F
0 R766 1-234-182-11 ENCAPSULATED COMPONENT
0 R767 1-249-393-11 CARBON 10 5% 1/4W F
0 R768 1-249-389-11 CARBON 4.7 5% 1/4W F
R769 1-249-425-11 CARBON 4.7K 5% 1/4W F
R770 1-249-437-11 CARBON 47K 5% 1/4W
R771 1-247-850-11 CARBON 6.2K 5% 1/4W
R772 1-249-419-11 CARBON 1.5K 5% 1/4W F
R773 1-249-437-11 CARBON 47K 5% 1/4W
R775 1-249-439-11 CARBON 68K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R780 1-249-429-11 CARBON 10K 5% 1/4W
R791 1-249-425-11 CARBON 4.7K 5% 1/4W F
R792 1-215-868-00 METAL OXIDE 680 5% 1W
0 R793 1-249-404-00 CARBON 82 5% 1/4W F
R794 1-215-868-00 METAL OXIDE 680 5% 1W
0 R802 1-249-409-11 CARBON 220 5% 1/4W F
0 R803 1-249-389-11 CARBON 4.7 5% 1/4W F
R804 1-249-426-11 CARBON 5.6K 5% 1/4W
R806 1-249-433-11 CARBON 22K 5% 1/4W
0 R910 1-243-635-11 FUSIBLE 0.33 5% 1/2W
< RELAY >
RY501 1-515-921-11 RELAY
RY560 1-755-267-11 RELAY
RY601 1-515-921-11 RELAY
RY701 1-515-921-11 RELAY
RY791 1-515-921-11 RELAY
< TERMINAL >
TM601 1-694-805-11 TERMINAL BOARD (CENTER/SURROUND)
TM602 1-694-785-11 TERMINAL BOARD (FRONT)
************************************************************
POWER BOARD
************
< CONNECTOR >
* CNP102 1-564-518-11 PLUG, CONNECTOR 3P
< SWITCH >
S152 1-771-410-21 SWITCH, TACTILE (?/1)
************************************************************
1-686-904-11 STANDBY BOARD
**************
< CAPACITOR >
C813 1-164-159-11 CERAMIC 0.1uF 50V
C814 1-164-159-11 CERAMIC 0.1uF 50V
C815 1-126-943-11 ELECT 2200uF 20.00% 25V
C816 1-126-942-61 ELECT 1000uF 20.00% 25V
C920 1-164-159-11 CERAMIC 0.1uF 50V
C921 1-164-159-11 CERAMIC 0.1uF 50V
C923 1-126-959-11 ELECT 0.47uF 20.00% 50V
C950 1-126-936-11 ELECT 3300uF 20.00% 16V
< CONNECTOR >
CNP901 1-564-321-00 PIN, CONNECTOR(3.96mm PITCH)2P
* CNP902 1-565-792-11 PIN, CONNECTOR(3.96mm PITCH)2P
CNP903 1-564-506-11 PLUG, CONNECTOR 3P
CNP905 1-779-495-11 PLUG, CONNECTOR PIN 4P
CNP912 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D820 8-719-024-99 DIODE 11ES2-NTA2B
D821 8-719-024-99 DIODE 11ES2-NTA2B
D822 8-719-024-99 DIODE 11ES2-NTA2B
D823 8-719-024-99 DIODE 11ES2-NTA2B
D901 8-719-911-19 DIODE 1SS133T-72
D910 8-719-024-99 DIODE 11ES2-NTA2B
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-024-99 DIODE 11ES2-NTA2B
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-911-19 DIODE 1SS133T-72
D915 8-719-911-19 DIODE 1SS133T-72
< EARTH TERMINAL >
* G901 1-537-738-21 TERMINAL, EARTH
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
POWER STANDBY
