Sony STR-K650P - Electrical Parts List: Video and Volume Components

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
38
STR-K650P
< FUSE HOLDER >
FH901 1-533-293-11 FUSE HOLDER
FH902 1-533-293-11 FUSE HOLDER
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q921 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
< RESISTOR >
0 R810 1-243-634-91 FUSIBLE 0.22 5% 1/2W
0 R812 1-243-634-91 FUSIBLE 0.22 5% 1/2W
0 R901 1-219-237-91 SOLID 3.3M 20% 1/2W
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W F
0 R904 1-249-381-11 CARBON 1 5% 1/4W F
R921 1-249-437-11 CARBON 47K 5% 1/4W
R922 1-249-435-11 CARBON 33K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
T902 1-435-281-11 TRANSFORMER, POWER
************************************************************
A-4731-175-A VIDEO BOARD, COMPLETE
*********************
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20.00% 50V
C207 1-126-964-11 ELECT 10uF 20.00% 50V
C208 1-126-964-11 ELECT 10uF 20.00% 50V
C210 1-126-964-11 ELECT 10uF 20.00% 50V
C213 1-126-934-11 ELECT 220uF 20.00% 16V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 2200PF 5% 50V
C809 1-126-934-11 ELECT 220uF 20.00% 16V
C824 1-164-159-11 CERAMIC 0.1uF 50V
C825 1-164-159-11 CERAMIC 0.1uF 50V
C827 1-126-947-11 ELECT 47uF 20.00% 25V
< CONNECTOR >
CNP156 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< CONNECTOR SOCKET >
CNS250 1-569-315-11 SOCKET, CONNECTOR 5P
< DIODE >
D203 8-719-911-19 DIODE 1SS133T-72
D204 8-719-911-19 DIODE 1SS133T-72
< IC >
IC103 6-701-890-01 IC NJM2595D
IC804 8-759-701-65 IC NJM79M05FA
IC807 8-759-039-69 IC uPC7805AHF
< JACK >
J200 1-794-978-11 JACK, PIN 3P (VIDEO1,VIDEO2,DVD)
J201 1-815-043-11 JACK, PIN 2P (VIDEO1,MONITOR)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
VOLUME BOARD
**************
< CONNECTOR >
* CNP104 1-564-518-11 PLUG, CONNECTOR 3P
< VARIABLE RESISTOR >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
************************************************************
MISCELLANEOUS
**************
0 57 1-783-532-11 CORD, POWER
61 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
62 1-693-577-22 TUNER
65 1-575-662-31 WIRE (FLAT TYPE) (5 CORE)
0 F901 1-576-109-11 FUSE 6.3A/125V
Q503 8-749-010-25 IC MN2488-OPY-M
Q504 8-749-010-26 IC MP1620-OPY-M
Q603 8-749-010-25 IC MN2488-OPY-M
Q604 8-749-010-26 IC MP1620-OPY-M
Q653 8-749-010-25 IC MN2488-OPY-M
Q654 8-749-010-26 IC MP1620-OPY-M
Q703 8-749-010-25 IC MN2488-OPY-M
Q704 8-749-010-26 IC MP1620-OPY-M
Q753 8-749-010-25 IC MN2488-OPY-M
Q754 8-749-010-26 IC MP1620-OPY-M
0 T901 1-437-995-11 POWER TRANSFORMER
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
STANDBY VIDEO VOLUME
