Sony STR-K980 - Printed Wiring Board - STANDBY Board

3131
STR-K980
STR-K980
POWER TRANSFORMER
(SUB)
E
1
1
6
5
E
1
3
AC
IN
12
A
B
C
D
E
F
3456789101112
(CHASSIS)
12
V
SPEAKER B
BOARD
CNP807
(Page 34)
D
DIGITAL
BOARD
CNP505
(Page 19)
N
MAIN
BOARD
CN915
(Page 25)
Q
MAIN
BOARD
CNP802
(Page 25)
T901
POWER TRANSFORMER
(MAIN)
3-16. PRINTED WIRING BOARD – STANDBY BOARD –
:Uses unleaded solder.
• See page 15 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D901 A-5
D910 C-3
D911 B-3
D912 C-2
D913 B-3
D914 B-3
D915 C-3
D920 E-3
D921 E-3
D922 E-3
D923 E-3
Q901 B-2
Q921 D-3
