52
STR-K980
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R111 1-249-415-11 CARBON 680 5% 1/4W
R115 1-247-807-31 CARBON 100 5% 1/4W
R116 1-247-807-31 CARBON 100 5% 1/4W
R117 1-247-807-31 CARBON 100 5% 1/4W
R118 1-249-440-11 CARBON 82K 5% 1/4W
R119 1-247-807-31 CARBON 100 5% 1/4W
0 R121 1-249-393-11 CARBON 10 5% 1/4W
R122 1-247-804-11 CARBON 75 5% 1/4W
R123 1-249-429-11 CARBON 10K 5% 1/4W
R131 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R198 1-249-381-11 CARBON 1 5% 1/4W
0 R199 1-249-381-11 CARBON 1 5% 1/4W
< VARIABLE RESISTOR >
RV101 1-418-817-11 ENCODER, ROTARY (INPUT SELECTOR)
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S101 1-771-410-21 SWITCH, TACTILE (SPEED/X-ROUND)
S102 1-771-410-21 SWITCH, TACTILE (MODE/X-ROUND)
S103 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S104 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S105 1-771-410-21 SWITCH, TACTILE (MOVIE)
S106 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S107 1-771-410-21 SWITCH, TACTILE (2CH)
S108 1-771-410-21 SWITCH, TACTILE (MEMORY/ENTER)
S109 1-771-410-21 SWITCH, TACTILE (TUNING MODE)
S110 1-771-410-21 SWITCH, TACTILE (–/TUNING)
S111 1-771-410-21 SWITCH, TACTILE (+/TUNING)
S124 1-771-410-21 SWITCH, TACTILE (MUSIC)
*************************************************************
HEADPHONE BOARD
****************
< CAPACITOR >
C790 1-127-888-11 CERAMIC 0.1uF 10% 50V
C791 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J791 1-815-314-21 JACK (PHONES)
< TEST PIN >
* TP701 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
A-1188-347-A MAIN BOARD, COMPLETE
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C400 1-127-888-11 CERAMIC 0.1uF 10% 50V
C403 1-127-888-11 CERAMIC 0.1uF 10% 50V
C408 1-126-963-11 ELECT 4.7uF 20% 50V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C444 1-127-868-11 CERAMIC 2200PF 10% 50V
C453 1-162-286-31 CERAMIC 220PF 10% 50V
C458 1-126-963-11 ELECT 4.7uF 20% 50V
C459 1-126-963-11 ELECT 4.7uF 20% 50V
C463 1-162-286-31 CERAMIC 220PF 10% 50V
C464 1-127-888-11 CERAMIC 0.1uF 10% 50V
C468 1-162-282-31 CERAMIC 100PF 10% 50V
C469 1-162-282-31 CERAMIC 100PF 10% 50V
C471 1-126-963-11 ELECT 4.7uF 20% 50V
C472 1-126-963-11 ELECT 4.7uF 20% 50V
C481 1-126-964-11 ELECT 10uF 20% 50V
C484 1-126-964-11 ELECT 10uF 20% 50V
C485 1-126-964-11 ELECT 10uF 20% 50V
C488 1-127-888-11 CERAMIC 0.1uF 10% 50V
C492 1-126-964-11 ELECT 10uF 20% 50V
C493 1-126-964-11 ELECT 10uF 20% 50V
C495 1-126-964-11 ELECT 10uF 20% 50V
C499 1-162-286-31 CERAMIC 220PF 10% 50V
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C503 1-104-658-91 ELECT 100uF 20% 10V
C504 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C505 1-102-233-00 CERAMIC 33PF 10% 500V
C506 1-162-282-31 CERAMIC 100PF 10% 50V
C507 1-162-282-31 CERAMIC 100PF 10% 50V
C510 1-126-947-11 ELECT 47uF 20% 35V
C511 1-136-157-00 FILM 0.022uF 5% 50V
C516 1-162-815-11 CERAMIC 47PF 5% 500V
C517 1-162-815-11 CERAMIC 47PF 5% 500V
C519 1-162-286-31 CERAMIC 220PF 10% 50V
C529 1-127-876-11 CERAMIC 0.01uF 10% 50V
C540 1-126-964-11 ELECT 10uF 20% 50V
C541 1-127-876-11 CERAMIC 0.01uF 10% 50V
C601 1-126-963-11 ELECT 4.7uF 20% 50V
C603 1-104-658-91 ELECT 100uF 20% 10V
C604 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C605 1-102-233-00 CERAMIC 33PF 10% 500V
C606 1-162-282-31 CERAMIC 100PF 10% 50V
C607 1-162-282-31 CERAMIC 100PF 10% 50V
C610 1-126-947-11 ELECT 47uF 20% 35V
C611 1-136-157-00 FILM 0.022uF 5% 50V
C619 1-162-286-31 CERAMIC 220PF 10% 50V
C620 1-162-815-11 CERAMIC 47PF 5% 500V
C621 1-162-815-11 CERAMIC 47PF 5% 500V
C640 1-126-964-11 ELECT 10uF 20% 50V
C642 1-127-876-11 CERAMIC 0.01uF 10% 50V
C651 1-126-963-11 ELECT 4.7uF 20% 50V
C653 1-104-658-91 ELECT 100uF 20% 10V
C654 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C655 1-102-233-00 CERAMIC 33PF 10% 500V
C656 1-162-282-31 CERAMIC 100PF 10% 50V
C657 1-162-282-31 CERAMIC 100PF 10% 50V
C660 1-126-947-11 ELECT 47uF 20% 35V
C661 1-136-157-00 FILM 0.022uF 5% 50V
C666 1-162-815-11 CERAMIC 47PF 5% 500V
C669 1-162-815-11 CERAMIC 47PF 5% 500V
