Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
46
BD CLAMP MOTOR CONNECTOR IN SW INT/COUNT SW LEAF SW
R147 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-001-00 METAL CHIP 10 5% 1/10W
R158 1-216-111-00 METAL CHIP 390K 5% 1/10W
R159 1-216-101-00 METAL CHIP 150K 5% 1/10W
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES, CHIP 16K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-077-91 RES, CHIP 15K 5% 1/10W
R181 1-216-078-00 RES, CHIP 16K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-077-91 RES, CHIP 15K 5% 1/10W
< NETWORK RESISTOR >
RN101 1-233-412-11 RES, CHIP NETWORK 1.0K (3216)
RN102 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
* 1-671-507-21 CLAMP MOTOR BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C711 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN712 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-109-69 DIODE MTZJ-T-77-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W
**************************************************************
* 1-671-506-21 CONNECTOR BOARD
*****************
< CONNECTOR >
CN701 1-568-860-11 SOCKET, CONNECTOR 17P
< TRANSISTOR >
Q701 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R707 1-249-424-11 CARBON 3.9K 5% 1/4W
R708 1-249-417-11 CARBON 1K 5% 1/4W
R709 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
* 1-671-505-21 IN SW BOARD
************
< CONNECTOR >
* CN710 1-568-941-11 PIN, CONNECTOR 3P
< SWITCH >
S703 1-771-218-11 SWITCH, MICRO (MID IN)
S704 1-771-218-11 SWITCH, MICRO (IN)
**************************************************************
* 1-671-502-21 INT/COUNT SW BOARD
*******************
< SWITCH >
S705 1-771-264-11 SWITCH, PUSH (DETECTION) (1KEY) (INIT)
S706 1-771-264-11 SWITCH, PUSH (DETECTION) (1KEY) (COUNT)
**************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< CABLE HOLDER >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< PHOTO INTERRUPTER >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W
R1002 1-249-409-11 CARBON 220 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
To Next Page
