7
BACK PANEL ASS’Y
MAIN BOARD
3
four screws
(BVTP3
×
10)
3
seven screws
(BVTP3
×
10)
4
claw
4
claw
5
back panel ass’y
2
connector
(CN173)
1
flat wire (CN1
)
2
two screws
(BVTP3
×
10)
1
connector (CN111)
1
two connectors
(CN161, 181)
3
connector (CN152)
4
main board
