Sony STR-NX3 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
47
LEAF SW LOAD MOTOR MAIN
R1008 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1KEY) (DECK A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1KEY) (DECK B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF)
S1004 1-771-205-11 SWITCH, LEAF (DECK A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (DECK A REC)
S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF)
S1008 1-771-205-11 SWITCH, LEAF (DECK B 120/70)
S1009 1-771-205-11 SWITCH, LEAF (DECK B REC)
**************************************************************
* 1-671-508-21 LOAD MOTOR BOARD
******************
< CAPACITOR >
C703 1-162-306-11 CERAMIC 0.01uF 30% 16V
C704 1-126-964-11 ELECT 10uF 20% 50V
C712 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN713 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D702 8-719-109-85 DIODE MTZJ-T-77-5.1B
< IC >
IC702 8-759-633-65 IC M54641L
< RESISTOR >
R703 1-249-411-11 CARBON 330 5% 1/4W
R704 1-249-401-11 CARBON 47 5% 1/4W
**************************************************************
A-4426-608-A MAIN BOARD, COMPLETE (US, CND, AEP, UK)
A-4426-609-A MAIN BOARD, COMPLETE
(MY, SP, KR, AUS, JE)
A-4426-945-A MAIN BOARD, COMPLETE (TH)
*************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 SLIT
< CAPACITOR >
C001 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-104-665-11 ELECT 100uF 20% 10V
C102 1-164-159-11 CERAMIC 0.1uF 50V
C103 1-164-159-11 CERAMIC 0.1uF 50V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-164-159-11 CERAMIC 0.1uF 50V
C108 1-104-665-11 ELECT 100uF 20% 10V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-104-665-11 ELECT 100uF 20% 10V
C111 1-126-925-11 ELECT 470uF 20% 10V
C112 1-126-925-11 ELECT 470uF 20% 10V
C118 1-216-916-11 ELECT 1000uF 20% 6.3V
C119 1-161-494-00 CERAMIC 0.022uF 25V
C120 1-164-159-11 CERAMIC 0.1uF 50V
C121 1-164-159-11 CERAMIC 0.1uF 50V
(US, CND, AEP, UK)
C123 1-162-282-31 CERAMIC 100PF 10% 50V
C124 1-162-282-31 CERAMIC 100PF 10% 50V
C128 1-162-306-11 CERAMIC 0.01uF 30% 16V
C129 1-104-665-11 ELECT 100uF 20% 10V
C301 1-126-960-11 ELECT 1uF 20% 50V
C302 1-137-368-11 FILM 0.0047uF 5% 50V
C303 1-136-165-00 FILM 0.1uF 5% 50V
C304 1-136-165-00 FILM 0.1uF 5% 50V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-126-960-11 ELECT 1uF 20% 50V
C307 1-126-959-11 ELECT 0.47uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-137-194-81 FILM 0.47uF 5% 50V
C310 1-162-290-31 CERAMIC 470PF 10% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-959-11 ELECT 0.47uF 20% 50V
C313 1-162-294-31 CERAMIC 0.001uF 10% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-963-11 ELECT 4.7uF 20% 50V
C316 1-104-665-11 ELECT 100uF 20% 10V
C317 1-104-665-11 ELECT 100uF 20% 10V
C333 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C334 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C335 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C336 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C351 1-126-960-11 ELECT 1uF 20% 50V
C352 1-137-368-11 FILM 0.0047uF 5% 50V
C353 1-136-165-00 FILM 0.1uF 5% 50V
C354 1-136-165-00 FILM 0.1uF 5% 50V
C355 1-126-964-11 ELECT 10uF 20% 50V
C356 1-126-960-11 ELECT 1uF 20% 50V
C357 1-126-959-11 ELECT 0.47uF 20% 50V
C358 1-126-964-11 ELECT 10uF 20% 50V
C359 1-137-194-81 FILM 0.47uF 5% 50V
C360 1-162-290-31 CERAMIC 470PF 10% 50V
C701 1-126-961-11 ELECT 2.2uF 20% 50V
C751 1-126-961-11 ELECT 2.2uF 20% 50V
C801 1-126-964-11 ELECT 10uF 20% 50V
C802 1-126-964-11 ELECT 10uF 20% 50V
C813 1-104-664-11 ELECT 47uF 20% 25V
C853 1-126-944-11 ELECT 3300uF 20% 25V
C854 1-126-944-11 ELECT 3300uF 20% 25V
C855 1-126-964-11 ELECT 10uF 20% 50V
C861 1-126-768-11 ELECT 2200uF 20% 16V
C862 1-104-665-11 ELECT 100uF 20% 10V
C865 1-104-665-11 ELECT 100uF 20% 10V
C866 1-126-964-11 ELECT 10uF 20% 50V
C867 1-126-934-11 ELECT 220uF 20% 10V
C868 1-126-934-11 ELECT 220uF 20% 10V
C869 1-104-664-11 ELECT 47uF 20% 25V
C870 1-164-159-11 CERAMIC 0.1uF 50V
