Sony STR-NX3 Service Manual

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
49
MAIN OUT SW PANEL
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
R142 1-249-429-11 CARBON 10K 5% 1/4W
R143 1-249-429-11 CARBON 10K 5% 1/4W
R144 1-249-411-11 CARBON 330 5% 1/4W
R145 1-249-429-11 CARBON 10K 5% 1/4W
R146 1-247-807-31 CARBON 100 5% 1/4W
R147 1-249-417-11 CARBON 1K 5% 1/4W
R148 1-249-417-11 CARBON 1K 5% 1/4W
R149 1-249-425-11 CARBON 4.7K 5% 1/4W
R150 1-249-425-11 CARBON 4.7K 5% 1/4W
R151 1-249-429-11 CARBON 10K 5% 1/4W
R152 1-249-429-11 CARBON 10K 5% 1/4W
R153 1-249-429-11 CARBON 10K 5% 1/4W
R154 1-247-807-31 CARBON 100 5% 1/4W
R155 1-249-429-11 CARBON 10K 5% 1/4W
R156 1-249-429-11 CARBON 10K 5% 1/4W
R157 1-249-429-11 CARBON 10K 5% 1/4W
R158 1-249-429-11 CARBON 10K 5% 1/4W
R159 1-249-429-11 CARBON 10K 5% 1/4W
R160 1-249-429-11 CARBON 10K 5% 1/4W
R161 1-247-807-31 CARBON 100 5% 1/4W
R162 1-249-429-11 CARBON 10K 5% 1/4W
R163 1-249-429-11 CARBON 10K 5% 1/4W
R164 1-247-807-31 CARBON 100 5% 1/4W
R165 1-247-807-31 CARBON 100 5% 1/4W
R166 1-247-807-31 CARBON 100 5% 1/4W
R167 1-249-429-11 CARBON 10K 5% 1/4W
R168 1-247-807-31 CARBON 100 5% 1/4W
R169 1-249-429-11 CARBON 10K 5% 1/4W
R171 1-249-437-11 CARBON 47K 5% 1/4W
R301 1-249-435-11 CARBON 33K 5% 1/4W
R302 1-249-421-11 CARBON 2.2K 5% 1/4W
R303 1-247-807-31 CARBON 100 5% 1/4W
R304 1-247-807-31 CARBON 100 5% 1/4W
R305 1-249-421-11 CARBON 2.2K 5% 1/4W
R306 1-249-428-11 CARBON 8.2K 5% 1/4W
R307 1-249-428-11 CARBON 8.2K 5% 1/4W
R308 1-249-425-11 CARBON 4.7K 5% 1/4W
R309 1-249-433-11 CARBON 22K 5% 1/4W
R311 1-247-903-00 CARBON 1M 5% 1/4W
R312 1-247-884-11 CARBON 160K 5% 1/4W
R313 1-249-441-11 CARBON 100K 5% 1/4W
R315 1-249-429-11 CARBON 10K 5% 1/4W
R316 1-249-432-11 CARBON 18K 5% 1/4W
R317 1-249-429-11 CARBON 10K 5% 1/4W
R318 1-249-429-11 CARBON 10K 5% 1/4W
R319 1-247-893-11 CARBON 390K 5% 1/4W
R321 1-249-422-11 CARBON 2.7K 5% 1/4W
R322 1-249-428-11 CARBON 8.2K 5% 1/4W
R324 1-247-876-11 CARBON 75K 5% 1/4W
R325 1-247-876-11 CARBON 75K 5% 1/4W
R326 1-249-417-11 CARBON 1K 5% 1/4W
R327 1-249-437-11 CARBON 47K 5% 1/4W
R328 1-249-425-11 CARBON 4.7K 5% 1/4W
R329 1-249-437-11 CARBON 47K 5% 1/4W
R330 1-249-425-11 CARBON 4.7K 5% 1/4W
R331 1-249-437-11 CARBON 47K 5% 1/4W
R332 1-249-415-11 CARBON 680 5% 1/4W
R333 1-249-421-11 CARBON 2.2K 5% 1/4W
R334 1-249-415-11 CARBON 680 5% 1/4W
R335 1-249-421-11 CARBON 2.2K 5% 1/4W
R336 1-249-437-11 CARBON 47K 5% 1/4W
R337 1-249-417-11 CARBON 1K 5% 1/4W
R338 1-249-411-11 CARBON 330 5% 1/4W
R339 1-249-437-11 CARBON 47K 5% 1/4W
R340 1-249-437-11 CARBON 47K 5% 1/4W
R341 1-249-417-11 CARBON 1K 5% 1/4W
R342 1-249-411-11 CARBON 330 5% 1/4W
R343 1-249-437-11 CARBON 47K 5% 1/4W
R351 1-249-435-11 CARBON 33K 5% 1/4W
R352 1-249-421-11 CARBON 2.2K 5% 1/4W
R353 1-247-807-31 CARBON 100 5% 1/4W
R354 1-247-807-31 CARBON 100 5% 1/4W
R355 1-249-421-11 CARBON 2.2K 5% 1/4W
R356 1-249-428-11 CARBON 8.2K 5% 1/4W
R357 1-249-428-11 CARBON 8.2K 5% 1/4W
R358 1-249-425-11 CARBON 4.7K 5% 1/4W
R359 1-249-435-11 CARBON 33K 5% 1/4W
R701 1-247-807-31 CARBON 100 5% 1/4W
R702 1-249-435-11 CARBON 33K 5% 1/4W
R751 1-247-807-31 CARBON 100 5% 1/4W
R752 1-249-435-11 CARBON 33K 5% 1/4W
R802 1-247-815-91 CARBON 220 5% 1/4W
R855 1-249-417-11 CARBON 1K 5% 1/4W
R859 1-249-417-11 CARBON 1K 5% 1/4W
0 R861 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
0R862 1-212-956-00 FUSIBLE 8.2 5% 1/2W F
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< VIBRATOR >
X101 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
* 1-671-503-21 OUT SW BOARD
*************
< CONNECTOR >
* CN709 1-568-943-11 PIN, CONNECTOR 5P
CN715 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S701 1-771-218-11 SWITCH, MICRO (MID OUT)
S702 1-771-218-11 SWITCH, MICRO (LID)
S708 1-771-218-11 SWITCH, MICRO (OUT)
**************************************************************
A-4426-223-A PANEL BOARD, COMPLETE (EXCEPT TH)
A-4426-942-A PANEL BOARD, COMPLETE (TH)
**************************
< CONNECTOR >
CN204 1-784-782-11 CONNECTOR, FFC 21P
