Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
51
PANEL TC-A PANEL TC-B SENSOR SENSOR 2
1-674-773-11 PANEL TC-A BOARD
****************
< RESISTOR >
R246 1-247-843-11 CARBON 3.3K 5% 1/4W
R247 1-249-425-11 CARBON 4.7K 5% 1/4W
< SWITCH >
S227 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S228 1-762-875-21 SWITCH, KEYBOARD (DOLBY NR)
**************************************************************
1-674-772-11 PANEL TC-B BOARD
****************
< LED >
D216 8-719-071-41 LED SELS5923C-TP15 (CD SYNC)
D217 8-719-071-44 LED SELS5223C-TP15 (REC PAUSE/START)
< RESISTOR >
R241 1-249-407-11 CARBON 150 5% 1/4W
R242 1-249-409-11 CARBON 220 5% 1/4W
R243 1-249-427-11 CARBON 6.8K 5% 1/4W
R244 1-249-429-11 CARBON 10K 5% 1/4W
R245 1-249-431-11 CARBON 15K 5% 1/4W
< SWITCH >
S224 1-762-875-21 SWITCH, KEYBOARD (HI DUB)
S225 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S226 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
**************************************************************
* 1-671-504-21 SENSOR BOARD
*************
< CONNECTOR >
CN708 1-506-481-11 PIN, CONNECTOR 2P
< LED >
D704 8-719-055-84 LED GL528VS1 (DISC IN DETECT SENSOR)
< RESISTOR >
R711 1-249-415-11 CARBON 680 5% 1/4W
**************************************************************
* 1-671-789-21 SENSOR 2 BOARD
***************
4-220-274-01 HOLDER (SENSOR) (//C)
< PHOTO TRANSISTOR >
Q703 8-729-926-31 PHOTO TRANSISTOR PT483F1
**************************************************************
MISCELLANEOUS
**************
1 1-773-040-11 WIRE (FLAT TYPE) (17 CORE) (12cm)
2 1-791-433-11 WIRE (FLAT TYPE) (19 CORE)
5 1-791-075-11 CORD, CONNECTION
61 1-773-170-11 WIRE (FLAT TYPE) (21 CORE)
67 1-773-004-11 WIRE (FLAT TYPE) (15 CORE)
68 1-773-044-11 WIRE (FLAT TYPE) (17 CORE) (16cm)
0 253 8-820-026-03 OPTICAL PICK-UP KSM-213BFN/C2NP
257 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 A-2056-681-A DECK (A) ASSY, HEAD (PLAYBACK)
HRPE101A-2056-682-A DECK (B) ASSY, HEAD (REC/PB/ERASE)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-2646-110-3 MOTOR ASSY, SPINDLE
M102 X-2625-769-1 MOTOR ASSY, SLED
M701 X-4950-341-1 MOTOR (CLAMP) ASSY
(ELEVATOR UP/DOWN)
M702 X-4950-342-1 MOTOR (LOADING) ASSY
S707 1-418-045-01 ENCODER, ROTARY
(DISC TRAY ADDRESS DETECT)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-853-04 SCREW +BVTT 2X6 (S)
#3 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#4 7-685-851-04 SCREW +BVTT 2X4 (S)
#5 7-628-254-50 SCREW +PS 2.6X16
#6 7-628-254-15 SCREW +PS 2.6X6
#7 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#8 7-685-870-01 SCREW +BVTT 3X5 (S)
#9 7-685-862-11 SCREW +BVTT 2.6X6 (S)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
